| Specification |
Details |
| Model |
9907-331 |
| Series |
723PLUS |
| Type |
Digital speed and load control |
| Power Supply |
18–40 VDC, < 20 W nominal |
| Speed Inputs |
2 channels, Magnetic Pickup Unit (MPU) or proximity switch, 1–60 Vrms, 100 Hz–20 kHz |
| Analog Inputs |
4 channels, 4–20 mA or 0–5 VDC (configurable) |
| Discrete Inputs |
8 channels, optically isolated, 18–40 VDC |
| Analog Outputs |
2 channels, 4–20 mA or 0–200 mA for actuators |
| Relay Outputs |
4 channels, Form C, 5 A at 250 VAC |
| Communication |
2 LON channels (DSLC and LinkNet), 2 serial ports (RS-232/RS-422, Modbus-compatible) |
| Control Modes |
Isochronous, droop, base loading, process control |
| Features |
Torsional filter, self-diagnostic processor/memory tests, permanent memory storage, adjustable dynamics |
| Operating Temperature |
-40°C to +70°C (-40°F to +158°F) |
| Storage Temperature |
-55°C to +105°C (-67°F to +221°F) |
| Relative Humidity |
5% to 95%, non-condensing |
| Vibration |
4 G, 5–500 Hz |
| Shock |
20 G peak |
| Protection Rating |
Not specified (designed for control cabinet use) |
| Dimensions |
Approximately 305 mm x 254 mm x 51 mm (12 in x 10 in x 2 in) |
| Weight |
Approximately 2 kg (4.4 lbs) |
| Mounting |
Panel or rack mount, sheet-metal chassis |
| Certifications |
CE, UL/cUL for Class 1 Div. 2, Groups A/B/C/D |
| System Compatibility |
Woodward DSLC, LinkNet-HT, SPM-A synchronizers, diesel/gas engines, turbines |
