Woodward 9907-175 2301D-ST Digital Load Sharing
Woodward 9907-175 2301D-ST Digital Load Sharing
Manufacturer: Woodward
Product No.: 9907-175
Condition:1000 in stock
Product Type: 2301D-ST Digital Load Sharing
Product Origin: USA
Payment: T/T, Western Union
Weight: 3000g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Woodward 9907-175 2301D-ST Digital Load Sharing
Product Overview
- The Woodward 9907-175 is a 2301D-ST Digital Load Sharing and Speed Control, designed for precise speed and load control of small steam turbines driving generators, pumps, or compressors in industrial applications such as power generation, oil and gas, and process industries. This microprocessor-based control unit is part of Woodward__ 2301D series, offering advanced digital control for single-valve steam turbines with isochronous or droop speed governing, load sharing, and protection functions. The 2301D-ST is tailored for steam turbine applications, providing automated startup, shutdown, and precise speed regulation. The 9907-175 is a specific variant of the 2301D-ST, featuring a high-voltage power supply (88_132 VAC or 90_150 VDC) and potentially specific firmware or configurations compared to other 2301D models (e.g., 9907-173). It integrates with Woodward actuators and supports communication with plant control systems. The 9907-175 features a rugged design for reliable operation in harsh environments. It is distinct from Woodward__ genset controls like the EasyGen series (e.g., 8440-2179 EasyGen-3500XT, 9907-1182), DSLC series (e.g., 9905-976, 8923-1262), 505 series (e.g., 9907-163, 9905-792), 2301A series (e.g., 9905-463), EGCP-3 series (e.g., 8444-1082), SPM-D2 series (e.g., 8446-1048), SPM-A series (e.g., 9907-028), MicroNet Plus (e.g., 8800-1001), TG-13 (e.g., 8516-050), Peak150 series (e.g., 8200-176), ProAct series (e.g., 8237-2595), 723PLUS series (e.g., 8270-1013), EPG systems (e.g., 8290-195), electronic governors (e.g., 8406-121), and actuators (e.g., 8408-921), focusing on digital control for small steam turbines.
Technical Specifications
- The 9907-175 has the following specifications based on industry sources and Woodward documentation:
| Specification | Details |
|---|---|
| Model/Part Number | 9907-175 |
| Manufacturer | Woodward |
| Description | 2301D-ST Digital Load Sharing and Speed Control for Steam Turbines |
| Series | 2301D |
| Function | Controls steam turbine speed and load; manages load sharing, startup, shutdown, and protection |
| Processor | Microprocessor-based (specific architecture not publicly detailed) |
| Memory | Flash: 8_16 MB (for firmware and configuration) RAM: 4_8 MB (for runtime data) |
| Display | No integrated display; uses external PC-based interface (Woodward Watch Window or Toolkit) or HMI |
| Inputs | 4 analog inputs (configurable for 4_20 mA, 0_5 V, e.g., pressure, temperature) 8 discrete inputs (24 VDC, e.g., start, stop) 1 speed input (magnetic pickup or proximity probe, 1_30 kHz) |
| Outputs | 2 analog outputs (4_20 mA or 0_200 mA for actuator control) 4 relay outputs (dry contact, up to 250 VAC/5 A, for alarms, trips) 1 actuator output (configurable for Woodward actuators, 4_20 mA or PWM) |
| Communication Interfaces | 1 serial port (RS-232/RS-485, Modbus RTU) 1 CANopen port (optional, for Woodward devices) Ethernet (optional, Modbus TCP) |
| Control Modes | Isochronous speed control, droop speed control, isochronous load sharing, auto start/stop sequences |
| Protection Functions | Overspeed, actuator fault, loss of speed signal, configurable alarms |
| Redundancy | Non-redundant |
| Diagnostics | Fault detection, event logging (up to 300 events), real-time data trending, status LEDs |
| Compatibility | Woodward actuators (e.g., EGB, ProAct, CPC-II, 8408-921), magnetic pickups, synchronizers (e.g., DSLC, SPM-A); interfaces with third-party devices via Modbus or analog signals |
| Power Supply | 88_132 VAC (50/60 Hz) or 90_150 VDC |
| Power Consumption | Approx. 10_25 W |
| Environmental Specifications | Operating Temperature: -40°C to +70°C (-40°F to +158°F) Storage Temperature: -40°C to +85°C (-40°F to +185°F) Relative Humidity: 5% to 95% non-condensing Vibration: IEC 60068-2-6 compliant Shock: IEC 60068-2-27 compliant |
| Enclosure | IP20 (requires control cabinet); optional IP54 with enclosure |
| Dimensions | Approx. 305 mm (H) x 254 mm (W) x 76 mm (D) |
| Weight | Approx. 2_3 kg |
| Mounting | Panel-mounted or DIN-rail (with adapter) |
| Certifications | CE, UL, CSA, marine certifications (e.g., DNV, ABS, Lloyd__ Register); ATEX/IECEx Zone 2 (configuration-dependent) |
