Product Description
Woodward 9907-1182 Rev B EasyGen-3200-5 Genset Control
Product Overview
- The Woodward 9907-1182 Rev B is an EasyGen-3200-5, a versatile genset control unit designed for advanced control, monitoring, and protection of diesel, gas, or dual-fuel generator sets in industrial power generation applications. This microprocessor-based controller is part of Woodward’s EasyGen-3000 series, offering comprehensive synchronization, load sharing, power management, and engine protection for single or multiple generator systems, including parallel operation with other gensets or utility grids. The EasyGen-3200-5 supports automatic start/stop, breaker control, and power factor regulation, making it suitable for complex power systems in industrial, marine, and critical facilities. The 9907-1182 Rev B is a specific variant of the EasyGen-3200-5, featuring Revision B firmware or hardware updates, which may include enhanced performance, additional features, or improved compatibility compared to earlier revisions or other EasyGen models (e.g., 8440-2050). It includes a graphical display and robust communication protocols for seamless integration with SCADA/DCS systems. The 9907-1182 Rev B is distinct from Woodward’s DSLC series (e.g., 9905-976, 8923-1262), SPM-A series (e.g., 9907-028, 9905-001K), SPM-D2 series (e.g., 8446-1048), 505 series (e.g., 9905-792, 9905-864), 2301A series (e.g., 9905-463), EGCP-3 series (e.g., 8444-1082), MicroNet Plus (e.g., 8800-1001), TG-13 (e.g., 8516-050), Peak150 series (e.g., 8200-176), ProAct series (e.g., 8237-2595), 723PLUS series (e.g., 8270-1013), EPG systems (e.g., 8290-195), electronic governors (e.g., 8406-121), and actuators (e.g., 8408-921), focusing on comprehensive genset control and power management.
Technical Specifications
- The 9907-1182 Rev B has the following specifications based on industry sources and Woodward documentation:
| Specification | Details |
|---|---|
| Model/Part Number | 9907-1182 Rev B |
| Manufacturer | Woodward |
| Description | EasyGen-3200-5 Genset Control for Generator Sets |
| Series | EasyGen-3000 |
| Function | Controls and monitors generator sets; manages synchronization, load sharing, power management, and protection |
| Processor | Microprocessor-based (specific architecture not publicly detailed) |
| Memory | Flash: 16–32 MB (for firmware and configuration) RAM: 8–16 MB (for runtime data) |
| Display | Graphical LCD, 320x240 pixels, multilingual support |
| Inputs | 12 analog inputs (configurable for 4–20 mA, 0–10 V, RTD, or thermocouples) 16 discrete inputs (24 VDC) 3 voltage inputs (generator, busbar, utility, 100–690 VAC) 3 current inputs (1 A or 5 A CTs) |
| Outputs | 4 analog outputs (4–20 mA or 0–10 V) 12 relay outputs (dry contact, up to 250 VAC/5 A, for breaker control, alarms) 1 actuator output (4–20 mA or PWM, for governor control) |
| Communication Interfaces | 2 CANopen ports (for engine ECUs, Woodward devices) 1 RS-232/RS-485 port (Modbus RTU) 1 Ethernet port (Modbus TCP, Woodward protocols) 1 USB port (for configuration) |
| Control Modes | Automatic start/stop, synchronization, isochronous/droop load sharing, active/reactive power control, power factor control, grid-parallel operation, emergency standby |
| Protection Functions | Over/under voltage, over/under frequency, reverse power, overcurrent, overspeed, loss of excitation, ground fault |
| Redundancy | Non-redundant (system-level redundancy via multiple units) |
| Diagnostics | Fault detection, event logging (up to 1,000 events), real-time data trending, graphical alarm display, remote diagnostics |
| Compatibility | Woodward governors (e.g., 2301D, 505, 723PLUS), actuators (e.g., UG-260, ProAct, 8408-921), engine ECUs (J1939/CANopen), synchronizers, and third-party devices via Modbus; integrates with SCADA/DCS systems |
| Power Supply | 12–24 VDC (8–40 VDC range) |
| Power Consumption | Approx. 15–30 W |
| Environmental Specifications | Operating Temperature: -20°C to +70°C (-4°F to +158°F) Storage Temperature: -30°C to +80°C (-22°F to +176°F) Relative Humidity: 5% to 95% non-condensing Vibration: IEC 60068-2-6 compliant Shock: IEC 60068-2-27 compliant |
| Enclosure | IP54 (front panel, when properly mounted); IP20 (rear) |
| Dimensions | Approx. 282 mm (H) x 219 mm (W) x 84 mm (D) |
| Weight | Approx. 2.5–3.5 kg |
| Mounting | Panel-mounted |
| Certifications | CE, UL, CSA, marine certifications (e.g., DNV, ABS, Lloyd’s Register); ATEX/IECEx Zone 2 (configuration-dependent) |
