Woodward 9903-543 AGLC Automatic Generator Loading Control

Woodward 9903-543 AGLC Automatic Generator Loading Control

  • Manufacturer: Woodward

  • Product No.: 9903-543

  • Condition:1000 in stock

  • Product Type: AGLC Automatic Generator Loading Control

  • Product Origin: USA

  • Payment: T/T, Western Union

  • Weight: 1020g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

Woodward 9903-543 AGLC Automatic Generator Loading Control

  • Manufacturer: Woodward
  • Model/Part Number: 9903-543
  • Description: AGLC Automatic Generator Loading Control, 88–132 VAC, 50/60 Hz, for Baseload Control of 1–15 Generator Sets

Overview

  • The Woodward 9903-543 is an Automatic Generator Loading Control (AGLC) designed to manage soft loading and unloading of generator sets in load-sharing systems. It ensures smooth power transitions, minimizing equipment stress and maintaining stability during load changes. The unit is suitable for power generation, industrial, and commercial applications requiring precise load control for up to 15 generators.

Technical Specifications

Specification Details
Model 9903-543
Series AGLC
Type Automatic generator loading control
Input Voltage 88–132 VAC, 50/60 Hz
Power Consumption 2.5 VA
Generator Capacity Controls up to 15 generator sets
Control Signals Analog and digital
Features Breaker open contact, adjustable baseload, maximum load limit, adjustable electronic ramps
Cooling Passive air cooling
Chassis Metal
Operating Temperature -40°C to +65°C (-40°F to +149°F)
Storage Temperature -55°C to +105°C (-67°F to +221°F)
Vibration 4 G, 5–500 Hz
Dimensions 8.5 in W x 7.5 in H x 2 in D (21.6 cm x 19.1 cm x 5.1 cm)
Weight 2 lb 4 oz (1.02 kg)
Certifications CE
System Compatibility Woodward load-sharing systems, generator sets with auxiliary circuit breakers



View full details

Product Description

Woodward 9903-543 AGLC Automatic Generator Loading Control

  • Manufacturer: Woodward
  • Model/Part Number: 9903-543
  • Description: AGLC Automatic Generator Loading Control, 88–132 VAC, 50/60 Hz, for Baseload Control of 1–15 Generator Sets

Overview

  • The Woodward 9903-543 is an Automatic Generator Loading Control (AGLC) designed to manage soft loading and unloading of generator sets in load-sharing systems. It ensures smooth power transitions, minimizing equipment stress and maintaining stability during load changes. The unit is suitable for power generation, industrial, and commercial applications requiring precise load control for up to 15 generators.

Technical Specifications

Specification Details
Model 9903-543
Series AGLC
Type Automatic generator loading control
Input Voltage 88–132 VAC, 50/60 Hz
Power Consumption 2.5 VA
Generator Capacity Controls up to 15 generator sets
Control Signals Analog and digital
Features Breaker open contact, adjustable baseload, maximum load limit, adjustable electronic ramps
Cooling Passive air cooling
Chassis Metal
Operating Temperature -40°C to +65°C (-40°F to +149°F)
Storage Temperature -55°C to +105°C (-67°F to +221°F)
Vibration 4 G, 5–500 Hz
Dimensions 8.5 in W x 7.5 in H x 2 in D (21.6 cm x 19.1 cm x 5.1 cm)
Weight 2 lb 4 oz (1.02 kg)
Certifications CE
System Compatibility Woodward load-sharing systems, generator sets with auxiliary circuit breakers
