| Specification |
Details |
| Model |
8440-1878 |
| Series |
easYgen-2500 (P1 Package) |
| Type |
Microprocessor-based genset controller |
| Input Voltage |
12/24 VDC (6.5–40 VDC range) |
| Power Consumption |
< 10 W |
| PT Input |
Up to 300 VAC (FlexRange) |
| CT Input |
0–1 A or 0–5 A RMS (configurable) |
| Speed Input |
Magnetic Pickup Unit (MPU) or engine ECU via CAN |
| Operating Temperature |
-20°C to +70°C (-4°F to +158°F) |
| Storage Temperature |
-30°C to +80°C (-22°F to +176°F) |
| Relative Humidity |
5% to 95%, non-condensing |
| Protection Rating |
IP20 (IP54 with front panel seal) |
| Dimensions |
Approximately 219 mm x 171 mm x 61 mm (8.6 in x 6.7 in x 2.4 in) |
| Weight |
Approximately 0.8 kg (1.76 lbs) |
| Mounting |
Panel mount |
| Display |
Backlit LCD for measured values and configuration |
| Communication |
CANopen, SAE J1939, Modbus RTU, RS-232 |
| Inputs |
Up to 6 discrete inputs, 3 analog inputs |
| Outputs |
Up to 6 discrete outputs, relay-based |
| Event Recorder |
Up to 300 events with real-time clock (battery-backed, ~5 years) |
| Certifications |
CE, UL/cUL, CSA, GL, LR Marine |
| System Compatibility |
Diesel/gas engine generator sets, SAE J1939-compatible ECUs (e.g., Scania, MTU, Volvo, Deutz, Cummins, Perkins) |
