| Specification |
Details |
| Model |
8404-4005 |
| Series |
Electrically Powered Governor (EPG), Model 4024 |
| Type |
Rotary actuator |
| Input Voltage |
24 VDC |
| Power Consumption |
Up to 95 W (system maximum, including speed control) |
| Work Output |
0.34 J (0.25 ft-lb) over 30° full governor travel |
| Output Shaft |
0.375"-36 SAE serrated on both ends |
| Actuator Rotation |
30° |
| Speed Sensor Compatibility |
Magnetic Pickup Unit (MPU), typically 1500–3000 Hz |
| Compatible Speed Controls |
Woodward EPG speed controls (e.g., 8290-184, 8290-191, 8290-215) |
| Operating Temperature |
-40°C to +93°C (-40°F to +200°F) |
| Storage Temperature |
-55°C to +105°C (-67°F to +221°F) |
| Relative Humidity |
5% to 95%, non-condensing |
| Vibration |
US MIL-STD-810C, Method 514.2, Procedure I, Curve J, limited to 3 g |
| Shock |
US MIL-STD-810C, Method 516.2, Procedure I, 40 g input, 11 ms duration |
| Protection Rating |
IP20 |
| Weight |
Approximately 0.9 kg (2 lbs) |
| Dimensions |
Compact design, specific dimensions not publicly specified |
| Mounting |
Panel mount near engine, not directly on engine |
| Material |
Aluminum and steel, corrosion-treated |
| Certifications |
CE, EU Directive compliant |
| System Compatibility |
Diesel and gas engines, Woodward EPG systems |
