| Specification |
Details |
| Model |
8290-048 |
| Series |
Electrically Powered Governor (EPG) |
| Type |
Speed control module |
| Input Voltage |
12 or 24 VDC (selectable, 10–32 VDC range) |
| Power Consumption |
Up to 95 W |
| Control Modes |
Isochronous (constant speed), Droop (load-dependent speed) |
| Speed Sensor |
Magnetic Pickup Unit (MPU), 3000–6000 Hz typical |
| Actuator Compatibility |
Woodward actuators (e.g., 512, 524, 1712, 1724) |
| Actuator Output |
Configurable for specific actuator requirements |
| Fuse Rating |
10 A slow blow |
| Wire Size |
12 AWG or 14 AWG (depending on length) |
| Operating Temperature |
-40°C to +75°C (-40°F to +167°F) |
| Storage Temperature |
-55°C to +105°C (-67°F to +221°F) |
| Relative Humidity |
5% to 95%, non-condensing |
| Protection Rating |
IP20 |
| Dimensions |
Approximately 20 cm x 15 cm x 5 cm |
| Weight |
Approximately 1.5 kg |
| Mounting |
Engine-mounted or panel-mounted |
| Certifications |
CE, UL, CSA, EU Directives |
| System Compatibility |
Woodward EPG systems, diesel/gas engines |
