Woodward 8273-501 2301D Digital Load Sharing & Speed Control
Woodward 8273-501 2301D Digital Load Sharing & Speed Control
Manufacturer: Woodward
Product No.: 8273-501 2301D
Condition:1000 in stock
Product Type: Digital Load Sharing & Speed Control
Product Origin: USA
Payment: T/T, Western Union
Weight: 1720g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Woodward 8273-501 2301D Digital Load Sharing & Speed Control
- Manufacturer: Woodward
- Model/Part Number: 8273-501 (2301D)
- Description: 2301D Digital Load Sharing and Speed Control, 24 VDC Input, Ordinary Locations
Overview
- The Woodward 8273-501 is a 2301D Digital Load Sharing and Speed Control module designed to regulate the speed and load of generators driven by diesel or gaseous engines (prime movers). It is used in industrial applications such as power generation, oil and gas, and marine systems, providing precise control and proportional load sharing in parallel generator setups. Its microprocessor-based design enhances flexibility and compatibility with existing 2301A systems.
Technical Specifications
| Specification | Details |
|---|---|
| Model | 8273-501 (2301D) |
| Series | 2301D Digital Load Sharing and Speed Control |
| Type | Microprocessor-based digital control |
| Input Voltage | 18_40 VDC, 0.589 A maximum |
| Output Power for Discrete Inputs | 24 VDC, 800 mA maximum |
| Operating Modes | Isochronous, Droop, Base Load |
| Speed Sensor | 1 MPU (Magnetic Pickup Unit), 100_20,000 Hz at rated speed |
| Speed Range | 90_3600 RPM (synchronous generator speed) |
| Analog Inputs | 2 configurable analog inputs (4_20 mA or 0_5 V) |
| Analog Outputs | 1 configurable analog output (4_20 mA or 0_5 V) |
| Discrete Inputs | 8 switch inputs (3 configurable) |
| Discrete Outputs | 4 configurable relay driver outputs |
| Communication Ports | RS-232 (9-pin connector), RS-422, 1200_38,400 baud, full-duplex |
| Actuator Compatibility | Forward-acting (increase current to increase fuel); reverse-acting with mechanical backup |
| Load Sensor | Integrated load sensor for load sharing |
| Maximum Ambient Temperature | 70°C |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Protection Rating | IP20 |
| Dimensions | Approximately 27.5 cm x 17.5 cm x 5 cm |
| Weight | Approximately 1.72 kg |
| Mounting | Panel mount, sheet-metal chassis |
| Certifications | CE (EMC Directive 89/336/EEC), UL, CSA |
| System Compatibility | Compatible with 2301A, upgradable to 2301E |
