Woodward 8200-508 Digital Speed Control
Product Overview
- The Woodward 8200-508 is a Digital Speed Control, part of Woodward__ family of control systems designed for precise speed regulation of engines and turbines in industrial applications. This microprocessor-based control unit is typically used for controlling the speed of diesel or gas engines, small gas turbines, or other rotating machinery in applications such as power generation, marine propulsion, and industrial processes. The 8200-508 offers robust performance with integrated speed control, protection, and diagnostics, making it suitable for standalone or integrated systems. It is compact, cost-effective, and designed for reliable operation in non-critical applications. The 8200-508 is distinct from Woodward__ 505D series (e.g., 8200-1300), Peak150 series (e.g., 8200-176), and MicroNet systems (e.g., 5541-693), focusing on simpler speed control tasks.
Technical Specifications
- The 8200-508 has the following specifications_
| Specification | Details |
|---|---|
| Model/Part Number | 8200-508 |
| Manufacturer | Woodward |
| Description | Digital Speed Control for Engines and Small Turbines |
| Series | Not part of a specific named series (standalone digital speed control) |
| Function | Controls speed of diesel/gas engines or small gas turbines |
| Processor | Microprocessor-based (specific architecture not publicly detailed) |
| Memory | Flash: 4_8 MB (for firmware and configuration) RAM: 2_4 MB (for runtime data) |
| Display | None (configuration via PC interface or external HMI) |
| Inputs | 2 speed inputs (magnetic pickup or proximity probes) 4 analog inputs (4_20 mA or 0_5 V) 6 discrete inputs (24 VDC) |
| Outputs | 2 analog outputs (4_20 mA) 3 relay outputs (dry contact) 1 actuator output (4_20 mA or 0_200 mA) |
| Communication Interfaces | 1 serial port (RS-232 or RS-485, Modbus RTU) CANopen (optional) |
| Control Modes | Speed control, isochronous or droop operation |
| Redundancy | Non-redundant |
| Diagnostics | Fault detection, event logging (up to 200 events), status LEDs |
| Compatibility | Woodward actuators (e.g., UG-8, EGB), speed sensors, and third-party devices via standard protocols; integrates with basic SCADA systems |
| Power Supply | 18_32 VDC (24 VDC nominal) |
| Power Consumption | Approx. 10_20 W |
| Environmental Specifications | Operating Temperature: -40°C to +70°C (-40°F to +158°F) Storage Temperature: -40°C to +85°C (-40°F to +185°F) Relative Humidity: 5% to 95% non-condensing Vibration: MIL-STD-810 compliant Shock: MIL-STD-810 compliant |
| Enclosure | IP20 (panel-mounted, higher IP ratings with enclosures) |
| Dimensions | Approx. 200 mm (H) x 150 mm (W) x 100 mm (D) |
| Weight | Approx. 1.5_2 kg |
| Mounting | Panel or DIN rail |
| Certifications | CE, UL, CSA, marine certifications (e.g., DNV, ABS) for specific configurations |
