Woodward 5466-1156 MicroNet TMR CPU5200 Enhanced Module
Woodward 5466-1156 MicroNet TMR CPU5200 Enhanced Module
Manufacturer: Woodward
Product No.: 5466-1156
Condition:1000 in stock
Product Type: MicroNet TMR CPU5200 Enhanced Module
Product Origin: USA
Payment: T/T, Western Union
Weight: 1200g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Woodward 5466-1156 MicroNet TMR CPU5200 Enhanced Module
Product Overview
- The Woodward 5466-1156 is an enhanced CPU5200 Module designed for Woodward__ MicroNet Triple Modular Redundant (TMR) Control Systems. This module serves as the central processing unit for the MicroNet TMR platform, executing complex control algorithms, managing I/O communications, and ensuring fault-tolerant operation in critical industrial applications such as gas and steam turbines, compressors, and power generation systems. Its TMR architecture provides high reliability through triplicated processing with 2-out-of-3 voting, making it ideal for safety-critical environments. The 5466-1156 is commonly used in industries like power generation, oil and gas, aerospace, and marine, recognized for its advanced processing capabilities, enhanced memory, and robust integration with Woodward__ control ecosystem. It is an upgraded variant compared to models like 5466-1145, 5466-1050, and 5466-1049, potentially featuring improved performance, additional communication options, or firmware enhancements.
Technical Specifications
- The 5466-1156 has the following specifications based on industry sources and Woodward documentation:
| Specification | Details |
|---|---|
| Model/Part Number | 5466-1156 |
| Manufacturer | Woodward |
| Description | CPU5200 Enhanced Module for MicroNet TMR Control Systems |
| Series | MicroNet TMR |
| Function | Executes control algorithms, manages I/O, and ensures fault-tolerant operation |
| Processor | Triple redundant high-performance microprocessors (e.g., Freescale PowerPC QorIQ-based or similar advanced architecture) |
| Memory | Flash: 64_128 MB (for firmware and application) RAM: 256_512 MB (for runtime data) |
| Communication Interfaces | Ethernet (dual redundant ports, 10/100 Mbps), Modbus TCP/RTU, CANopen, RS-232, RS-485, Woodward proprietary protocols, potentially enhanced protocol support |
| Redundancy | Triple Modular Redundant (TMR) with 2-out-of-3 voting for fault tolerance |
| I/O Interface | Interfaces with MicroNet TMR I/O modules via internal high-speed bus |
| Control Software | Woodward GAP (Graphical Application Programmer), MicroNet Toolkit, Control Assistant |
| Diagnostics | Processor health monitoring, fault detection, discrepancy detection, event logging (up to 1000 events), status LEDs |
| Compatibility | Woodward MicroNet TMR systems, I/O modules (e.g., 5464-658 digital input, 5458-051 analog I/O, 5464-337 speed sensor), actuators, and third-party devices via standard protocols |
| Power Supply | 18_32 VDC (24 VDC nominal, via MicroNet chassis backplane) |
| Power Consumption | Approx. 25_40 W |
| Environmental Specifications | Operating Temperature: -40°C to +70°C (-40°F to +158°F) Storage Temperature: -40°C to +85°C (-40°F to +185°F) Relative Humidity: 5% to 95% non-condensing Vibration: MIL-STD-810 compliant Shock: MIL-STD-810 compliant |
| Enclosure | IP20 (installed in MicroNet chassis, higher IP ratings with enclosures) |
| Dimensions | Approx. 300 mm (H) x 50 mm (W) x 150 mm (D) |
| Weight | Approx. 0.8_1.2 kg |
| Mounting | Plugs into MicroNet TMR chassis |
| Certifications | CE, UL, CSA, ATEX (for hazardous areas, configuration-dependent), marine certifications (e.g., DNV, ABS) |
