Product Description
Product Overview
| Category | Details |
|---|---|
| Manufacturer | Woodward |
| Model/Part Number | 5464-458 |
| Description | Discrete Input Module designed for industrial control systems, providing reliable digital input monitoring |
| Key Features | 32-channel discrete inputs, part of the MicroNet series, robust design for turbine and engine control |
Technical Specifications
| Specification | Details |
|---|---|
| Model | 5464-458 |
| Product Line | MicroNet Digital Control System |
| Input Channels | 32 discrete inputs |
| Input Voltage | 24 VDC nominal |
| Update Time | 5 ms |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Weight | Approx. 0.8 kg (1.76 lbs) |
External Connection Options
| Connection Type | Details |
|---|---|
| Supported Connections | Field wiring via terminal blocks, connects to MicroNet motherboard within control chassis |
Functional Features
| Feature | Details |
|---|---|
| Input Monitoring | Receives and processes 32 discrete input signals from field devices |
| Fault Response | Inputs are monitored; system faults trigger appropriate control responses |
| Installation | Hot-swappable, slides into card guides and secures with two screws |
Model and Configuration
| Category | Details |
|---|---|
| Base Model | 5464-458 (Discrete Input Module, 32 channels, MicroNet series) |
| Configuration | Designed for use in Woodward MicroNet control systems, integrates with CPU module for signal processing |
