Product Description
Woodward 5458-051 MicroNet TMR Analog I/O Module
Product Overview
- The Woodward 5458-051 is an Analog Input/Output (I/O) Module designed for Woodward’s MicroNet Triple Modular Redundant (TMR) Control Systems. This module processes analog signals for both input and output, interfacing with sensors and actuators in critical industrial applications such as gas and steam turbines, compressors, and power generation systems. Its TMR architecture ensures fault-tolerant operation through triplicated signal processing with 2-out-of-3 voting, making it suitable for high-reliability environments. The 5458-051 is commonly used in industries like power generation, oil and gas, aerospace, and marine, known for its robust design and seamless integration with MicroNet TMR systems. It is similar to the Woodward 5458-050 but may feature specific configuration or firmware differences.
Technical Specifications
- The 5458-051 has the following specifications based on industry sources and Woodward documentation:
| Specification | Details |
|---|---|
| Model/Part Number | 5458-051 |
| Manufacturer | Woodward |
| Description | Analog Input/Output Module for MicroNet TMR Control Systems |
| Series | MicroNet TMR |
| Function | Processes triplicated analog input and output signals for control and monitoring |
| Analog Inputs | 8 channels (triplicated), 4–20 mA, 0–5 V, or ±10 V (configuration-dependent) |
| Analog Outputs | 4 channels (triplicated), 4–20 mA or 0–5 V (configuration-dependent) |
| Resolution | 16-bit for inputs, 14-bit for outputs (typical) |
| Accuracy | ±0.1% of full scale (typical) |
| Input Impedance | 250 Ω (for 4–20 mA), >1 MΩ (for voltage inputs) |
| Output Load | ≤ 600 Ω (for 4–20 mA), ≥ 2 kΩ (for voltage outputs) |
| Isolation | Optically isolated inputs/outputs (up to 1500 V) |
| Response Time | ≤ 10 ms (typical for input to output processing) |
| Redundancy | Triple Modular Redundant (TMR) with 2-out-of-3 voting for fault tolerance |
| Communication Interface | Internal MicroNet bus (proprietary protocol) |
| Diagnostics | Signal overrange/underrange, open circuit detection, discrepancy detection, status LEDs |
| Compatibility | Woodward MicroNet TMR systems, compatible with MicroNet CPUs (e.g., 5453-759, 5453-203) and I/O modules |
| Power Supply | 18–32 VDC (24 VDC nominal, via MicroNet chassis backplane) |
| Power Consumption | Approx. 15–25 W (depending on signal load) |
| Environmental Specifications | Operating Temperature: -40°C to +70°C (-40°F to +158°F) Storage Temperature: -40°C to +85°C (-40°F to +185°F) Relative Humidity: 5% to 95% non-condensing Vibration: MIL-STD-810 compliant Shock: MIL-STD-810 compliant |
| Enclosure | IP20 (installed in MicroNet chassis, higher IP ratings with enclosures) |
| Dimensions | Approx. 300 mm (H) x 50 mm (W) x 150 mm (D) |
| Weight | Approx. 0.6–1.0 kg |
| Mounting | Plugs into MicroNet TMR chassis |
| Certifications | CE, UL, CSA, ATEX (for hazardous areas, configuration-dependent), marine certifications (e.g., DNV, ABS) |
