Triconex 4200 Multi-Mode Fiber Optic Remote Extender Module
The Triconex 4200 Remote Extender Module (RXM) delivers robust, fault-tolerant I/O bus extension for safety-critical industrial control systems. Engineered with multi-mode fiber optic technology, this module enables seamless communication between Tricon controllers and remote I/O chassis across distances up to 2 kilometers while maintaining Triple Modular Redundant (TMR) architecture integrity.
Technical Specifications
- Model Number: 4200
- Transmission Medium: Multi-mode fiber optic cable
- Maximum Distance: Up to 2 km (6,562 ft)
- Architecture: Triple Modular Redundant (TMR)
- Communication Protocol: Proprietary Tricon I/O bus extension
- Isolation: Electrical isolation between controller and remote I/O
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Power Consumption: Low power design for energy efficiency
- Compatibility: Tricon v9 and later systems
Key Features & Benefits
Extended Reach with Signal Integrity: Multi-mode fiber optic transmission eliminates electromagnetic interference (EMI) concerns, ensuring reliable data transmission in electrically noisy industrial environments such as refineries, chemical plants, and power generation facilities.
Fault-Tolerant Design: Maintains TMR voting logic across extended distances, providing continuous operation even during single-point failures. The module supports hot-swappable redundancy for zero-downtime maintenance.
Simplified Installation: Standard fiber optic connectors and straightforward configuration reduce commissioning time. Compatible with existing Triconex infrastructure without requiring controller firmware upgrades.
Application Scenarios
Distributed Control Architecture: Ideal for facilities requiring I/O placement in hazardous zones while keeping controllers in safe areas. Common applications include offshore platforms, petrochemical complexes, and nuclear power stations.
Retrofit & Expansion Projects: Enables cost-effective system expansion without relocating main controllers. Perfect for brownfield projects where existing cable trays are at capacity or distance limitations prevent copper-based solutions.
High-Availability Systems: Critical for SIL 3-rated safety instrumented systems (SIS) where communication reliability directly impacts process safety and operational continuity.
Solution Integration
The Triconex 4200 integrates seamlessly with the complete Triconex ecosystem. Pair with Triconex 4211 Remote Extender Module for single-mode fiber applications requiring longer distances, or combine with Triconex 4201RXM for copper-based short-range extensions. For complete system architecture, consider the Triconex 4000212-020 Trident Extender Bus Assembly Kit for comprehensive installation support.
Frequently Asked Questions
Q: What is the maximum number of RXM modules per Tricon controller?
A: Each Tricon controller supports up to 14 remote chassis using RXM modules, with each chassis accommodating multiple I/O modules based on system configuration.
Q: Does the 4200 require special fiber optic cables?
A: The module uses standard 62.5/125 μm or 50/125 μm multi-mode fiber with ST or SC connectors. Cable specifications should meet minimum bandwidth requirements for reliable operation.
Q: Can I mix 4200 multi-mode and 4211 single-mode modules in the same system?
A: Yes, Triconex systems support mixed RXM configurations, allowing flexible network topology design based on distance and environmental requirements.
Q: What diagnostic capabilities does the module provide?
A: Built-in diagnostics monitor fiber link status, signal strength, and communication errors. Status LEDs provide real-time visual indication, while system software logs detailed fault information.
Warranty & Support
All Triconex 4200 modules include a comprehensive 12-month warranty covering manufacturing defects and performance issues. Our technical support team provides installation guidance, troubleshooting assistance, and configuration optimization to ensure maximum system uptime.
Related Products
| Product | Description | Link |
|---|---|---|
| Triconex 4211 RXM | Single-mode fiber optic extender for long-distance applications | View Product |
| Triconex 4201RXM | Copper-based remote extender for short-range I/O extension | View Product |
| Triconex 4000212-020 | Trident Extender Bus Assembly Kit for complete installation | View Product |
