| Module Type |
Triple Modular Redundant (TMR), Supervised Digital Output |
| Output Points |
8, commoned |
| Nominal Voltage |
115 V AC |
| Voltage Range |
90-155 V AC |
| Frequency Range |
47-63 Hz |
| Maximum Switching Power |
2000 VA (resistive load) |
| On-State Voltage Drop |
< 2 V, typical |
| Current Ratings |
2 A maximum per point, 10 A per AC cycle |
| Minimum Required Load |
50 mA |
| Chassis Leakage |
1 mA maximum at 60 Hz |
| Load Leakage |
4 mA maximum |
| Fuses |
1 per output (2.5 A fast-acting) |
| Point Isolation |
1500 V DC, minimum |
| Diagnostic Indicators |
Output Status (POINT, PWR, LOAD), Module Status (PASS, FAULT, ACTIVE) |
| Color Code |
Deep green |
| Operating Temperature |
0°C to 60°C (32°F to 140°F) |
| Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
| Humidity |
5% to 95% (non-condensing) |
| Mounting |
Plugs into Triconex chassis |
| Standards Compliance |
SIL 3 (IEC 61508), CE, UL, CSA, ATEX (for hazardous locations) |
