Triconex 3000671-100 Main Processor Baseplate
Product Overview
- Description: The Triconex 3000671-100 is a Main Processor Baseplate designed for use in Triconex safety instrumented systems (SIS), part of Schneider Electric’s Triconex product line.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Triconex (Schneider Electric) |
| Series | Triconex Safety Instrumented Systems (SIS) |
| Model/Part Number | 3000671-100 |
| Model Type | Main Processor Baseplate |
| Function | Mounts and powers Main Processor Modules, facilitates TMR communication |
| Display | Not applicable (no integrated display) |
| Inputs | Power inputs (24 VDC, typically) and communication signals from other modules |
| Outputs | Power and communication signals to Main Processor Modules |
| Communication Interfaces | TriBus for TMR communication, proprietary backplane connections |
| Signal Conditioning | Not applicable (power and signal distribution) |
| Accuracy | Not applicable |
| Redundancy | Supports Triple Modular Redundant (TMR) architecture |
| Diagnostics | Supported via Triconex system diagnostics and processor modules |
| Compatibility | Triconex safety systems (e.g., Tricon, Trident, Tri-GP) |
| Power Supply | 24 VDC (via external power source or chassis backplane) |
| Power Consumption | Minimal (passive baseplate, typically <5 W, excluding processors) |
| Environmental Specifications | Operating Temperature: -40°C to +70°C Storage Temperature: -40°C to +85°C Relative Humidity: 5% to 95% non-condensing |
| Enclosure | IP20 (when installed in Triconex chassis) |
| Dimensions | Approx. 483 mm (W) x 305 mm (H) x 50 mm (D) (estimated, chassis-dependent) |
| Weight | Approx. 2–3 kg (chassis-dependent) |
| Mounting | Rack-mounted in Triconex chassis |
| Certifications | CE, UL, CSA (system-dependent) |
