Product Description
Triconex 3000510-510 Terminal Panel Module
- Manufacturer: Triconex (Schneider Electric)
- Series: Tricon
- Model/Part Number: 3000510-510
- Description: Terminal Panel Module for Tricon systems
Overview
The Triconex 3000510-510 is a Terminal Panel Module designed for use in Triconex’s Tricon safety instrumented systems (SIS), part of Schneider Electric’s portfolio. It serves as a critical interface for connecting field devices to Triconex input/output (I/O) modules
Technical Specifications
| Specification | Details |
|---|---|
| Model | 3000510-510 |
| Series | Tricon |
| Type | Terminal Panel Module |
| Function | Provides terminal connections for field devices to Triconex I/O modules |
| Terminal Connections | Supports analog (0–5 VDC, 0–10 VDC) and digital signals |
| Isolation | Electrical isolation to protect against noise and interference |
| Connectors | Terminal blocks for field wiring, proprietary Triconex I/O interconnect |
| Compatibility | Tricon systems, integrates with Triconex I/O modules (e.g., 3604E, 3700A) and Main Processors (e.g., 3008) |
| Mounting | Mounts on Tricon chassis or external panel |
| Power Supply | Supplied by Tricon chassis backplane (typically 24 VDC) |
| Power Consumption | Approx. 2–4 W |
| Operating Temperature | -40°C to +70°C (-40°F to +158°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Relative Humidity | 5% to 95% (non-condensing) |
| Environmental Protection | Designed for harsh industrial environments; EMI/RFI shielding |
| Dimensions | Approx. 200 mm x 150 mm x 50 mm (7.9 x 5.9 x 2.0 in) |
| Weight | Approx. 0.8 kg (1.76 lbs) |
| Certifications | TÜV-certified for SIL 3 (IEC 61508), CE, UL, CSA, marine-certified, nuclear 1E-certified |
| Manual | Tricon Planning and Installation Guide |
