| Input Channels |
16 digital inputs, isolated in groups |
| Input Voltage |
24 V DC nominal (18-30 V DC) |
| Input Current |
7 mA per channel at 24 V DC |
| Isolation |
Channel-to-channel and channel-to-bus isolation (500 V) |
| Signal Types |
Supports sinking or sourcing inputs, configurable filtering |
| Power Supply |
24 V DC (from system backplane) |
| Power Consumption |
5 W maximum |
| Operating Temperature Range |
-30°C to +70°C |
| Mounting |
DIN rail or rack mount in control cabinet |
| Dimensions |
160 mm x 100 mm x 50 mm (W x H x D) approximate |
| Weight |
0.5 kg |
| Protection Rating |
IP20 |
| Standards Compliance |
IEC 61131-2, CE, UL, CSA |
