Product Description
Siemens A5E36358260 Analog Input Module
Product Overview
- The Siemens A5E36358260 is an Analog Input Module designed for use with Siemens SIMATIC S7-1200 programmable logic controller (PLC) systems. This module, part of the SIMATIC S7-1200 signal module family, is used to acquire analog signals from field devices such as sensors and transmitters in industrial automation applications. It is commonly employed in industries like manufacturing, chemical processing, water treatment, and building automation for precise measurement of process variables such as temperature, pressure, or flow. The module is compact, supports high-resolution signal processing, and integrates seamlessly with S7-1200 systems for small to medium-scale automation tasks.
Technical Specifications
- The A5E36358260 has the following specifications
| Specification | Details |
|---|---|
| Model/Part Number | A5E36358260 |
| Manufacturer | Siemens |
| Description | Analog Input Module (SM 1231, 4xAI, 13 Bit) |
| Series | SIMATIC S7-1200 |
| Function | Acquires analog signals from field devices (e.g., sensors, transmitters) |
| Input Channels | 4 analog inputs (differential or single-ended) |
| Input Signal Types | Current: 0/4–20 mA Voltage: ±10 V, 0–10 V |
| Resolution | 13 bit (12 bit + sign) |
| Accuracy | ±0.1% of full scale (typical) |
| Conversion Time | Approx. 2 ms per channel |
| Isolation | Galvanic isolation between channels and backplane bus (500 V AC) |
| Diagnostics | Wire break, overrange/underrange detection |
| Communication | Via S7-1200 CPU backplane (PROFINET or Modbus with CPU) |
| Compatibility | SIMATIC S7-1200 CPUs (e.g., CPU 1211C, 1214C, 1215C) |
| Power Supply | 24 VDC (via S7-1200 backplane or external) |
| Power Consumption | Approx. 1.5 W |
| Environmental Specifications | Operating Temperature: -20°C to +60°C (-4°F to +140°F) Storage Temperature: -40°C to +70°C (-40°F to +158°F) Relative Humidity: 5% to 95% non-condensing Vibration: IEC 60068-2-6 compliant Shock: IEC 60068-2-27 compliant |
| Dimensions | Approx. 70 mm (H) x 45 mm (W) x 75 mm (D) |
| Weight | Approx. 0.15 kg |
| Mounting | Snaps onto DIN rail or S7-1200 system |
| Certifications | CE, UL, CSA, FM, optional ATEX for hazardous areas (Zone 2) |
