Product Description
Product Overview
- The Siemens 6SR3902-0AJ00-0AD0 is a Power Supply Module designed for use in Siemens’ SICAM A8000 series, specifically for automation and remote terminal unit (RTU) applications. This module provides stable DC power to SICAM A8000 devices, ensuring reliable operation in industrial automation, energy management, and utility applications such as power distribution, renewable energy, and water treatment. The 6SR3902-0AJ00-0AD0 is part of the modular SICAM A8000 system, known for its compact design, high reliability, and suitability for harsh environments.
Technical Specifications
- The 6SR3902-0AJ00-0AD0 has the following specifications
| Specification | Details |
|---|---|
| Model/Part Number | 6SR3902-0AJ00-0AD0 |
| Manufacturer | Siemens |
| Description | Power Supply Module for SICAM A8000 Series |
| Series | SICAM A8000 |
| Function | Provides DC power to SICAM A8000 automation/RTU devices |
| Input Voltage | 24–60 VDC |
| Output Voltage | 5 VDC and 24 VDC (dual output) |
| Output Power | Up to 30 W (configuration-dependent) |
| Output Current | Max. 5 A at 5 VDC, 0.5 A at 24 VDC (typical) |
| Efficiency | >85% (typical) |
| Protection Features | Overvoltage, overcurrent, short-circuit protection |
| Compatibility | SICAM A8000 series (e.g., CP-8000, CP-8021, CP-8022) |
| Communication | No direct communication; power supply only |
| Environmental Specifications | Operating Temperature: -40°C to +70°C (-40°F to +158°F) Storage Temperature: -40°C to +85°C (-40°F to +185°F) Relative Humidity: 5% to 95% non-condensing Vibration: IEC 60068-2-6 compliant Shock: IEC 60068-2-27 compliant |
| Dimensions | Approx. 90 mm (H) x 45 mm (W) x 110 mm (D) |
| Weight | Approx. 0.3–0.5 kg |
| Mounting | Snaps onto DIN rail or SICAM A8000 base unit |
| Certifications | CE, UL, CSA, IEC 61850, optional ATEX for hazardous areas |
