Product Description
General Information
|
Field |
Details |
|---|---|
|
Manufacturer |
Siemens |
|
Model/Part Number |
6SN1118-0DJ23-0AA2 |
|
Series |
SIMODRIVE 611 |
|
Product Description |
Spare Part SIMODRIVE 611 Digital Control Loop Block High Performance, 1 Axis SIN/COS 1 Vpp Direct Measuring System, NC Software Required from 06.04.09 |
|
Product Group |
9313 |
|
Group Code |
R2S3 |
|
Country of Origin |
Germany |
Description
The 6SN1118-0DJ23-0AA2 is a high-performance 1-axis control loop block used in Siemens SIMODRIVE 611 digital drive systems. It supports:
-
SIN/COS 1 Vpp direct measuring systems
-
NC Software compatibility required from 06.04.2009
It is categorized as a spare part, used primarily for system maintenance and servicing of existing SIMODRIVE installations.
Technical Specifications
|
Specification |
Value |
|---|---|
|
Axis Support |
1 Axis |
|
Measuring System Support |
SIN/COS 1 Vpp Direct |
|
NC Software Compatibility |
Required from 06.04.2009 |
|
Net Weight |
0.480 kg |
|
Mounting |
Installed within SIMODRIVE chassis |
|
Control Type |
Digital control loop block |
Compliance & Environmental
|
Category |
Details |
|---|---|
|
Product Lifecycle Status |
PM410: Cancelled since 01.04.2015 |
|
RoHS Compliance |
Not compliant |
|
REACH Article 33 |
Contains Lead (CAS No. 7439-92-1 > 0.1% w/w) |
|
SCIP Number |
a458bbb0-276f-495e-a713-f4d842248748 |
|
WEEE Take-Back Obligation |
No |
|
Product Class |
C: Custom/produced-to-order, non-returnable, non-reusable |
Ordering & Logistics
|
Field |
Details |
|---|---|
|
Article Number |
6SN1118-0DJ23-0AA2 |
|
EAN |
4019169393300 |
|
UPC |
040892544800 |
|
Commodity Code |
85049090 |
|
Catalog ID (LKZ_FDB) |
SD.NC60 |
