Product Description
General Information
|
Field |
Details |
|---|---|
|
Manufacturer |
Siemens |
|
Model/Part Number |
6GK5784-1AA30-2AA0 |
|
Product Name |
SCALANCE W784-1 (Spare Part) |
|
Product Description |
Industrial Wireless LAN access point (IWLAN), IEEE 802.11b/g/a/h, 2.4/5 GHz, 54 Mbps, 1 radio, PoE, external antennas, only for use outside the USA, available only as spare part. |
|
Product Lifecycle |
PM500: Discontinued Product (End of lifecycle: 01.10.2024) |
|
Availability |
Not available for new purchase – only as a spare part |
|
Net Weight |
0.290 kg |
|
Successor Product |
Entire SCALANCE W700 series (IEEE 802.11n) recommended as successor |
Technical Specifications
|
Specification |
Details |
|---|---|
|
Wireless Standard |
IEEE 802.11b/g/a/h |
|
Frequency Bands |
2.4 GHz and 5 GHz |
|
Max Data Rate |
Up to 54 Mbps |
|
Encryption/Security |
WPA2, IEEE 802.11i, 802.11e |
|
Radio Interfaces |
1 radio |
|
Antenna Connections |
2x external antenna connections |
|
Ethernet Interface |
1x RJ45 (twisted pair), 10/100 Mbps |
|
Power Supply |
24 V DC / Power over Ethernet (PoE) |
|
IP Rating |
IP30 |
|
Operating Temperature Range |
-20 °C to +60 °C |
|
Scope of Delivery |
Documentation on CD-ROM (German/English) |
|
Installation |
Indoor (industrial) |
|
Approvals |
Observe national approvals |
Identification & Classification
|
Field |
Value |
|---|---|
|
Article Number |
6GK5784-1AA30-2AA0 |
|
EAN |
4019169155755 |
|
UPC |
Not available |
|
Commodity Code |
85176200 |
|
Catalog ID |
IK-E |
|
Product Group |
X0AH |
|
Group Code |
R323 |
|
Country of Origin |
Germany |
Environmental & Compliance Information
|
Field |
Details |
|---|---|
|
RoHS Compliance |
Yes |
|
REACH Article 33 (SVHC) |
Contains Lead (CAS 7439-92-1) > 0.1% |
|
SCIP Number |
8f5f10db-d7f1-426b-a98c-e58ba66f7a2b |
|
WEEE Directive (2012/19/EU) |
Take-back obligation: Yes |
|
Product Class |
A: Standard product, returnable per return guidelines |
