Product Description
General Information
|
Field |
Details |
|---|---|
|
Manufacturer |
Siemens |
|
Model/Part Number |
6GK5766-1GE00-7DA0 |
|
Product Name |
SCALANCE WAM766-1 |
|
Product Description |
IWLAN Access Point, 1 radio, 2.4/5 GHz, IEEE 802.11ax (Wi-Fi 6), 1201 Mbps per radio, supports iFeatures via CLP, rugged IP65 design, M12 connectors, -30 to +60 °C, PoE and redundant power support. |
|
Product Family |
SCALANCE WAM766-1 for indoor use |
|
Product Lifecycle |
PM300: Active Product |
|
Net Weight |
0.500 kg |
Technical Specifications
|
Specification |
Details |
|---|---|
|
Frequency Bands |
2.4 GHz and 5 GHz |
|
Wi-Fi Standard |
IEEE 802.11ax (Wi-Fi 6) |
|
Radio Modules |
1 radio module |
|
Data Rate |
Up to 1201 Mbps gross per radio |
|
Antenna Ports |
2x N-Connect connectors |
|
Ethernet Port |
1x 10/100/1000 Mbps M12 socket |
|
Power Supply |
Redundant 24 V DC (M12 L-coded), Power over Ethernet (PoE) |
|
IP Rating |
IP65 |
|
Operating Temperature Range |
-30 °C to +60 °C |
|
Interface Features |
CLP slot for iFeatures, Digital Input/Output (DI/DO), A-coded |
|
Certifications |
Cert ID: MSAX65-W1-M12-E2FCC ID: LYHMSAX65V1Check national approvals |
|
Scope of Delivery |
Sealing caps for connections |
Identification & Classification
|
Field |
Value |
|---|---|
|
Article Number |
6GK5766-1GE00-7DA0 |
|
UPC |
195125169999 |
|
EAN |
4047622889923 |
|
Commodity Code |
85176200 |
|
Catalog ID |
IK |
|
Product Group |
2407 |
|
Group Code |
R323 |
|
Country of Origin |
Germany |
Environmental & Compliance Information
|
Field |
Details |
|---|---|
|
RoHS Compliance |
Yes |
|
Product Class |
A: Stock product, returnable within guidelines |
|
WEEE Directive (2012/19/EU) |
Not specified |
|
REACH Compliance |
Not explicitly listed, but RoHS compliant |
