Product Description
General Information
|
Manufacturer |
Siemens |
|---|---|
|
Model/Part Number |
6ES7512-1SK01-0AB0 |
|
Product Type Designation |
CPU 1512SP F-1 PN |
|
HW Functional Status |
FS05 |
|
Firmware Version |
V2.9 |
Product Functions
|
Parameter |
Value |
|---|---|
|
I&M Data |
Yes (I&M0 to I&M3) |
|
Module Swapping During Operation (Hot Swapping) |
Yes (Multi-hot swapping) |
|
Isochronous Mode |
Yes (Only with PROFINET, minimum OB 6x cycle of 625 µs) |
Engineering Compatibility
|
Parameter |
Value |
|---|---|
|
STEP 7 TIA Portal Configurable/Integrated |
From Version V17 (FW V2.9) / V13 SP1 Update 4 (FW V1.8) or higher |
Power Supply
|
Parameter |
Value |
|---|---|
|
Rated Value (DC) |
24 V |
|
Permissible Range (Lower Limit) |
19.2 V DC |
|
Permissible Range (Upper Limit) |
28.8 V DC |
|
Reverse Polarity Protection |
Yes |
Mains Buffering
|
Parameter |
Value |
|---|---|
|
Mains/Voltage Failure Stored Energy Time |
5 ms |
Input Current & Power
|
Parameter |
Value |
|---|---|
|
Rated Current Consumption |
0.6 A |
|
Maximum Current Consumption |
0.9 A |
|
Maximum Inrush Current |
4.7 A (Rated Value) |
|
I²t |
0.14 A²·s |
|
Infeed Power to Backplane Bus |
8.75 W |
|
Typical Power Loss |
5.6 W |
Memory Specifications
|
Parameter |
Value |
|---|---|
|
SIMATIC Memory Card Slots |
1 |
|
SIMATIC Memory Card Required |
Yes |
|
Integrated Work Memory (Program) |
300 kB |
|
Integrated Work Memory (Data) |
1 MB |
|
Maximum Load Memory (Plug-in SIMATIC Memory Card) |
32 GB |
Physical Dimensions
|
Parameter |
Value |
|---|---|
|
Width |
100 mm |
|
Height |
117 mm |
|
Depth |
75 mm |
Weight
|
Parameter |
Value |
|---|---|
|
Approximate Weight |
310 g |
