Siemens 6ES7400-0HR02-4AB0 S7-400 UR2-H Rack
Siemens 6ES7400-0HR02-4AB0 S7-400 UR2-H Rack
Manufacturer: Siemens
Product No.: 6ES7400-0HR02-4AB0
Condition:1000 in stock
Product Type: PLC Racks & Chassis
Product Origin: 4019169007276
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Siemens 6ES7400-0HR02-4AB0 Universal Rack UR2-H
18-Slot High-Performance Rack for SIMATIC S7-400 Advanced Controller Systems
The Siemens 6ES7400-0HR02-4AB0 is a precision-engineered universal rack (UR2-H) designed for SIMATIC S7-400 automation systems. This 18-slot rack provides a robust, modular foundation for building high-availability process control, manufacturing automation, and critical infrastructure systems that demand maximum reliability and scalability.
🏗️ Why S7-400 UR2-H Rack?
The S7-400 platform represents Siemens' flagship PLC architecture for mission-critical applications. The UR2-H rack is the backbone that enables:
- ✅ Maximum I/O Density – 18 slots accommodate CPUs, I/O modules, communication processors, and function modules
- ✅ Hot-Swap Capability – Replace modules during operation without system shutdown (with redundant power)
- ✅ Redundancy Support – Compatible with H-system (high-availability) configurations
- ✅ Scalable Architecture – Expand to 21 racks (378 slots total) via interface modules
- ✅ Industrial Durability – Rated for harsh environments (-25°C to +60°C, high vibration)
- ✅ Global Certifications – CE, UL, FM, ATEX, IECEx for worldwide deployment
📐 Technical Specifications
| Order Number | 6ES7400-0HR02-4AB0 |
| Product Family | SIMATIC S7-400 |
| Rack Type | UR2-H (Universal Rack, 18-slot, H-system compatible) |
| Slot Count | 18 slots (numbered 1-18) |
| Rack Length | 2000mm (78.7 inches) |
| Material | Aluminum profile rail with steel mounting brackets |
| Mounting | Horizontal wall/cabinet mounting (vertical mounting not supported) |
| Module Width | 25mm per slot (standard S7-400 module width) |
| Backplane Bus | S7-400 K-bus (communication) and P-bus (power distribution) |
| Power Supply Slots | Slots 1-3 (up to 3 redundant power supplies) |
| CPU Slots | Slots 2-18 (CPU typically in slot 3 or 4) |
| Max Power Consumption | Depends on installed modules (calculate per PS 407 capacity) |
| Operating Temperature | 0°C to +60°C (horizontal mounting) 0°C to +40°C (vertical mounting - not recommended) |
| Storage Temperature | -40°C to +70°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Vibration Resistance | IEC 60068-2-6: 5-9 Hz (3.5mm amplitude), 9-150 Hz (1g acceleration) |
| Shock Resistance | IEC 60068-2-27: 15g, 11ms half-sine pulse |
| EMC Compliance | CE, FCC Class A, EN 61000-6-2/4 |
| Safety Certifications | UL 508, cULus, FM Class I Div 2, ATEX Zone 2, IECEx |
| Protection Rating | IP20 (front panel) |
| Dimensions (L×H×D) | 2000mm × 290mm × 210mm |
| Weight | Approx. 8 kg (empty rack) |
| MTBF | >200,000 hours (proven in field installations) |
| Warranty | 24 months (manufacturer warranty) |
🔧 System Architecture & Slot Assignment
Recommended Slot Configuration
| Slot | Module Type | Notes |
|---|---|---|
| 1 | Power Supply (PS 407) | Primary power supply (mandatory) |
| 2 | Power Supply (PS 407) | Redundant power (optional, for H-systems) |
| 3 | CPU (e.g., CPU 414-3) | Central processing unit (typical position) |
| 4 | CPU (redundant) | For H-system configurations only |
| 5-18 | I/O, CP, FM modules | Signal modules, communication processors, function modules |
Compatible Module Types
- CPUs: CPU 412, 414, 416, 417 (standard and H-versions)
- Power Supplies: PS 407 series (4A, 10A, 20A variants)
- Digital I/O: SM 421, SM 422 (8-64 channels per module)
- Analog I/O: SM 431, SM 432 (2-16 channels, 12-16 bit resolution)
- Communication: CP 443-1 (Ethernet), CP 443-5 (Profibus DP)
- Function Modules: FM 450, FM 451, FM 452 (counting, positioning, control)
- Interface Modules: IM 460, IM 461 (for expansion racks)
🏭 Industry Applications
Oil & Gas Processing
Control offshore platforms, refineries, and pipeline systems with redundant S7-400H configurations. The UR2-H rack supports hot-swappable modules for zero-downtime maintenance in hazardous areas (ATEX/IECEx certified).
Power Generation & Distribution
Monitor and control turbines, generators, and substations. 18-slot capacity accommodates extensive I/O for SCADA integration, with deterministic cycle times for protective relay coordination.
Pharmaceutical Manufacturing
Ensure batch traceability and FDA 21 CFR Part 11 compliance with high-availability S7-400H systems. Rack supports redundant CPUs and power supplies for continuous production.
Automotive Assembly
Coordinate multi-robot welding lines, paint booths, and final assembly stations. Scalable architecture allows expansion to 21 racks (378 slots) for plant-wide control.
Water & Wastewater Treatment
Manage pumping stations, filtration systems, and chemical dosing with distributed I/O across multiple racks. Interface modules enable remote rack placement up to 10 meters apart.
🛠️ Installation & Commissioning Guide
Pre-Installation Planning
- Cabinet Selection – Ensure cabinet depth ≥250mm to accommodate rack + cable routing
- Power Budget Calculation – Sum module power consumption, select PS 407 capacity accordingly
- Cooling Requirements – Provide 50mm clearance above/below rack for ventilation
- Grounding Strategy – Plan equipotential bonding for EMC compliance
Mechanical Installation
- Position Rack – Mount horizontally at ergonomic height (1200-1500mm from floor)
- Secure Mounting – Use M6 screws through pre-drilled holes in rack profile
- Verify Alignment – Use level tool to ensure rack is perfectly horizontal (critical for module seating)
- Install Grounding – Connect rack to cabinet ground via M6 grounding stud
Module Installation Sequence
- Power Supply First – Install PS 407 in slot 1 (and slot 2 if redundant)
- CPU Installation – Insert CPU in slot 3 (or slots 3-4 for H-system)
- I/O Modules – Install signal modules from left to right (slots 5-18)
- Front Connectors – Attach pre-wired front connectors to each module
- Locking Mechanisms – Engage module locks to prevent accidental removal
Electrical Commissioning
- Power-Up Sequence – Energize PS 407, verify green OK LED
- CPU Initialization – Check CPU RUN/STOP switch, download program via STEP 7
- I/O Diagnostics – Use STEP 7 Hardware Config to verify all modules detected
- Functional Testing – Test each I/O point individually before production release
📊 Rack Expansion Options
| Configuration | Max Racks | Total Slots | Required Components |
|---|---|---|---|
| Single Rack | 1 | 18 | UR2-H rack + PS 407 + CPU |
| Central + 1 Expansion | 2 | 36 | + IM 460-0 (central) + IM 460-1 (expansion) + UR2 rack |
| Central + 5 Expansions | 6 | 108 | + 5× IM 460 pairs + 5× UR2 racks |
| Maximum Configuration | 21 | 378 | + 20× IM 460 pairs + 20× UR2 racks |
💡 Expansion Tip: Use IM 460-3 interface modules for distances up to 10 meters between racks. For longer distances, consider Profibus DP or Profinet IO distributed I/O.
📋 S7-400 Rack Comparison
| Model | Slots | Length | H-System Support | Best For |
|---|---|---|---|---|
| UR1 (6ES7400-1JA01-0AA0) | 9 | 530mm | No | Compact systems |
| UR2-H (6ES7400-0HR02-4AB0) | 18 | 2000mm | Yes | Standard/redundant systems |
| ER1 (6ES7400-1TA01-0AA0) | 9 | 530mm | No | Expansion racks |
| ER2 (6ES7400-1TA11-0AA0) | 18 | 2000mm | No | Large expansion racks |
| CR2 (6ES7400-2JA00-0AA0) | 18 | 2000mm | Yes | Central rack (alternative to UR2-H) |
🛡️ Authenticity & Quality Assurance
⚠️ Counterfeit Rack Risks
Non-genuine S7-400 racks can cause catastrophic failures:
- 🔥 Backplane Failures – Poor PCB quality causes intermittent communication errors
- ⚡ Power Distribution Issues – Inadequate P-bus design leads to voltage drops and module resets
- 💥 Mechanical Failures – Inferior aluminum alloys warp under module weight, causing poor contact
- 🚫 Certification Violations – Non-UL/ATEX racks void insurance and regulatory approvals
✅ Industrial Control Hub Guarantee
- 🔒 100% Genuine Siemens – Factory-sealed packaging with holographic security labels
- 📜 Full Traceability – Serial numbers and manufacturing dates on every rack
- 🌍 Authorized Distributor – Verify our credentials at Siemens Industry Mall
- 🛡️ 24-Month Warranty – Manufacturer warranty honored globally
- 📦 Protective Packaging – Custom crating prevents shipping damage to backplane
- 📞 Technical Support – Pre-sales system design consultation and post-sales integration assistance
📦 Package Contents
- 1× Siemens 6ES7400-0HR02-4AB0 UR2-H rack (18-slot, 2000mm)
- Mounting hardware kit (screws, grounding studs)
- Product documentation (installation manual, safety instructions)
- Certificate of conformity (upon request)
Note: Modules, power supplies, and front connectors are NOT included. Order separately based on your system requirements.
🔗 Essential Accessories
- Power Supply: PS 407 10A (6ES7407-0KA02-0AA0) – Recommended for most configurations
- CPU: CPU 414-3 PN/DP (6ES7414-3XM05-0AB0) – High-performance CPU with Profinet
- Interface Module: IM 460-0 (6ES7460-0AA01-0AB0) – For rack expansion
- Front Connectors: 6ES7492-1AL00-0AA0 (40-pin screw terminal)
- Labeling Strips: 6ES7492-2AX00-0AA0 (for module identification)
🤝 Technical Support & Services
Industrial Control Hub provides comprehensive support:
- 📧 System Design Consultation – Email us your I/O list for rack sizing and power budget analysis
- 📚 Documentation Library – Access Siemens manuals, CAD drawings, and configuration guides
- 🎓 Training Resources – STEP 7 programming tutorials and hardware configuration videos
- 🔧 Integration Assistance – Troubleshooting support for commissioning and diagnostics
- 🔄 30-Day Returns – Hassle-free returns if unused and in original packaging
❓ Frequently Asked Questions
Q: What's the difference between UR2-H and CR2 racks?
A: Both support H-systems, but UR2-H is a universal rack (can be central or expansion), while CR2 is specifically designed as a central rack with integrated interface module slots.
Q: Can I use this rack for S7-300 modules?
A: No, S7-400 racks are NOT compatible with S7-300 modules. Use 6ES7390-series racks for S7-300.
Q: How many power supplies do I need?
A: Minimum 1× PS 407 in slot 1. For redundancy (H-systems), install a second PS 407 in slot 2.
Q: What's the maximum distance between racks?
A: Up to 10 meters with IM 460-3 interface modules. For longer distances, use distributed I/O (Profibus DP/Profinet).
Q: Can I hot-swap modules during operation?
A: Yes, with redundant power supplies and proper STEP 7 configuration. Always follow Siemens hot-swap procedures to prevent data loss.
Q: Is vertical mounting supported?
A: Not recommended. Vertical mounting reduces operating temperature range to 0-40°C and may cause module seating issues.
