Siemens 6EP1336-2BA00 SITOP Power 20A Stabilized Power Supply 24V DC

Siemens 6EP1336-2BA00 SITOP Power 20A Industrial Power Supply

The Siemens 6EP1336-2BA00 SITOP power 20A delivers robust, stabilized 24V DC power for industrial automation and control systems. Designed for continuous operation in demanding manufacturing environments, this power supply converts 120/230V AC input to regulated 24V DC output at 20 amperes, providing reliable energy for PLCs, sensors, actuators, and field devices.

Key Technical Parameters

• Input Voltage: 120/230V AC (±15%), 50/60 Hz
• Output Voltage: 24V DC (adjustable 22.8-28.8V)
• Output Current: 20A continuous, 24A peak (5 seconds)
• Efficiency: >88% at nominal load
• Ripple: <150mV peak-to-peak
• Operating Temperature: -25°C to +70°C (derated above 60°C)
• Protection Class: IP20 housing
• Dimensions: 160mm x 310mm x 110mm (W x H x D)
• Mounting: DIN rail (35mm) or wall mount
• Certifications: UL, cUL, CE, RoHS compliant

Industrial Applications & Use Cases

This SITOP power supply excels in factory automation systems powering S7-300/400 PLCs, distributed I/O networks, and HMI panels. Common deployments include packaging lines requiring stable 24V DC for pneumatic valve manifolds, conveyor control systems with multiple motor starters, and process control installations with analog transmitters. The unit's wide input voltage tolerance makes it suitable for facilities with unstable grid power or generator-backed systems.

Engineered Solutions for Power Reliability

Advanced features include automatic restart after overload conditions, short-circuit protection with automatic recovery, and overvoltage shutdown to protect connected equipment. The adjustable output voltage allows compensation for voltage drops in long cable runs—critical for large installations. Built-in EMC filtering reduces electrical noise injection into sensitive control circuits, while the fanless convection cooling design eliminates maintenance requirements and acoustic emissions.

Installation & System Integration

Quick-connect spring-loaded terminals accept 0.5-6mm² conductors without tools, reducing installation time. Front-mounted LED indicators display AC OK, DC OK, and overload status for rapid diagnostics. Parallel operation capability enables N+1 redundancy configurations using SITOP diode modules. The compact 3-module width (160mm) conserves valuable panel space while delivering high power density of 125W per module width.

Frequently Asked Questions

Q: Can this power supply operate on 110V AC systems?
A: Yes, the wide input range (120/230V AC ±15%) accommodates 110V systems commonly found in North American industrial facilities.

Q: What is the recommended fuse size for input protection?
A: Use a 10A slow-blow fuse for 230V AC input or 16A for 120V AC input, per Siemens installation guidelines.

Q: Does this unit support redundant power configurations?
A: Yes, when combined with SITOP diode modules (6EP1961-2BA00), multiple units can be paralleled for N+1 redundancy.

Q: What is the expected service life?
A: With proper ventilation and ambient temperatures below 40°C, expect >100,000 hours MTBF based on Siemens reliability data.

Quality Assurance & Warranty

Every SITOP power supply undergoes 100% factory burn-in testing and quality inspection. Backed by a comprehensive 12-month warranty covering manufacturing defects and component failures, ensuring dependable operation in your critical infrastructure. Technical support available through authorized Siemens distributors and service centers worldwide.

Related Products You May Need

• Siemens 6EP1332-1SH71 SITOP PSU100S 5A Power Supply - Lower current option for smaller systems
• Siemens 6EP1334-2BA20 SITOP PSU200M 10A Power Supply - Mid-range power solution
• Siemens 6EP1457-3BA00 SITOP PSU8600 40A Power Supply - High-current industrial power
