Product Description
Product Overview
- The Siemens 6DP9905-8AA01 is a TELEPERM XP Dummy Front Plate designed for use in TELEPERM XP and SPPA automation systems. This component serves as a placeholder or cover for unused slots in AP/ER subracks, ensuring proper enclosure and protection of the rack's internal components. It is used in industrial automation environments, such as chemical processing, power generation, and manufacturing, to maintain system integrity and aesthetics in rack configurations.
Technical Specifications
- The 6DP9905-8AA01 has the following specifications based on industry sources:
| Specification | Details |
|---|---|
| Model/Part Number | 6DP9905-8AA01 |
| Manufacturer | Siemens |
| Description | TELEPERM XP Dummy Front Plate, 20 mm, for AP/ER Subrack |
| Series | TELEPERM XP |
| Function | Covers unused slots in AP/ER subracks to protect internal components and maintain enclosure integrity |
| Compatibility | AP/ER subracks in TELEPERM XP and SPPA systems |
| Material | Metal or high-strength plastic (typical for Siemens subrack components) |
| Environmental Specifications | Ambient Temperature: 0°C to +60°C Shock: 10 g ½ sine wave for 11 ms Vibration: 1 mm peak to peak from 2 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz Relative Humidity: 5% to 95% non-condensing |
| Dimensions | Approx. 233 mm (H) x 20 mm (W) x 2 mm (D) (standard TELEPERM XP front plate size) |
| Weight | Approx. 0.1 kg |
| Mounting | Attaches to AP/ER subrack via standard mounting mechanism |
| Certifications | CE, UL (as part of subrack compliance) |
Additional Details
- The 6DP9905-8AA01 includes the following additional information based on industry sources:
- Function: Acts as a protective cover for unused slots in AP/ER subracks, preventing dust ingress and maintaining electromagnetic shielding; ensures compliance with enclosure standards in TELEPERM XP and SPPA systems; does not perform active electrical functions.
