Product Description
Product Overview
- The Siemens 6DP1531-8AA is a TELEPERM XP FUM 531 Analog Signal Coupling Module designed for the TELEPERM XP automation system. This module facilitates the acquisition and output of analog signals, supporting 4 analog inputs and 4 analog outputs with electrical isolation. It is used in industrial automation applications, such as chemical processing, power generation, and manufacturing, for non-safety-related functions in the APF system, providing reliable signal coupling for process control.
Technical Specifications
- The 6DP1531-8AA has the following specifications based on industry sources:
| Specification | Details |
|---|---|
| Model/Part Number | 6DP1531-8AA |
| Manufacturer | Siemens |
| Description | TELEPERM XP FUM 531 Analog Signal Coupling Module |
| Series | TELEPERM XP |
| Function | Analog signal coupling: 4 analog inputs with electrical isolation 4 analog outputs (0 to 10 V, 2 to 10 V, 0 to 20 mA, 4 to 20 mA) Suitable for non-safety-related functions in the APF system |
| Input/Output | 4 analog inputs (current or voltage signals, galvanically isolated) 4 analog outputs (0 to 10 V, 2 to 10 V, 0 to 20 mA, 4 to 20 mA) |
| Power Supply | 24 VDC (via TELEPERM XP rack backplane) |
| Power Consumption | Approx. 10 W (estimated based on similar modules) |
| Environmental Specifications | Ambient Temperature: 0°C to +60°C Shock: 10 g ½ sine wave for 11 ms Vibration: 1 mm peak to peak from 2 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz Relative Humidity: 5% to 95% non-condensing |
| Dimensions | Approx. 233 mm (H) x 160 mm (W) x 20 mm (D) (standard TELEPERM XP module size) |
| Weight | Approx. 0.5 kg |
| Mounting | Plugs into TELEPERM XP rack |
| Certifications | CE, UL |
Additional Details
- The 6DP1531-8AA includes the following additional information based on industry sources:
- Function: Acquires 4 analog inputs with galvanic isolation for current or voltage signals; provides 4 analog outputs supporting multiple signal ranges (0 to 10 V, 2 to 10 V, 0 to 20 mA, 4 to 20 mA); designed for non-safety-related functions in the APF system, ensuring reliable signal coupling for process monitoring and control.
