Product Description
Product Overview
- The Siemens 6DP1511-8AA is a TELEPERM XP FUM 511 Binary Signal Coupling Module designed for the TELEPERM XP automation system. This module handles binary signal acquisition and processing, supporting 16 binary inputs and 16 binary outputs. It is used in industrial automation applications, such as chemical processing, power generation, and manufacturing, for reliable control and monitoring of binary signals, including integration with console control tiles in SPPA-T2000 systems.
Technical Specifications
- The 6DP1511-8AA has the following specifications based on industry sources:
| Specification | Details |
|---|---|
| Model/Part Number | 6DP1511-8AA |
| Manufacturer | Siemens |
| Description | TELEPERM XP FUM 511 Binary Signal Coupling Module |
| Series | TELEPERM XP |
| Function | Binary signal coupling: 16 binary inputs with electrical isolation via optocouplers 16 binary outputs, 250 mA (with limitation), steady or flashing (8, 2, 0.5 Hz) Suitable for connecting console control tiles, capable for 2 desk tiles in SPPA-T2000 |
| Input/Output | 16 binary inputs (24 VDC, isolated via optocouplers) 16 binary outputs (250 mA, steady or flashing at 8, 2, or 0.5 Hz) |
| Input Voltage | 24 VDC nominal (11–30 VDC range) |
| Power Supply | 24 VDC (via TELEPERM XP rack backplane) |
| Power Consumption | Approx. 10 W (estimated based on similar modules) |
| Environmental Specifications | Ambient Temperature: 0°C to +60°C Shock: 10 g ½ sine wave for 11 ms Vibration: 1 mm peak to peak from 2 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz Relative Humidity: 5% to 95% non-condensing |
| Dimensions | Approx. 233 mm (H) x 160 mm (W) x 20 mm (D) (standard TELEPERM XP module size) |
| Weight | Approx. 0.5 kg |
| Mounting | Plugs into TELEPERM XP rack |
| Certifications | CE, UL |
Additional Details
- The 6DP1511-8AA includes the following additional information based on industry sources:
- Function: Acquires and processes 16 binary inputs with electrical isolation via optocouplers for noise immunity; provides 16 binary outputs (250 mA) with configurable steady or flashing modes (8, 2, or 0.5 Hz); designed for connecting console control tiles, supporting up to 2 desk tiles in SPPA-T2000 systems; suitable for non-safety-related functions in automation processes.
