Product Description
Product Overview
- The Siemens 6DP1360-8BA is a TELEPERM XP FUM 360 Fail-Safe Counting Module designed for the TELEPERM XP automation system. This module is used for pulse counting, frequency measurement, and position detection in fail-safe applications, ensuring reliable operation in critical industrial processes. It supports up to 4 pulse inputs and is suitable for applications such as speed monitoring, flow measurement, and position control in industries like chemical processing, power generation, and oil and gas. The module is designed for redundant configurations to enhance system reliability.
Technical Specifications
- The 6DP1360-8BA has the following specifications based on industry sources:
| Specification | Details |
|---|---|
| Model/Part Number | 6DP1360-8BA |
| Manufacturer | Siemens |
| Description | TELEPERM XP FUM 360 Fail-Safe Counting Module for Pulse Counting and Frequency Measurement |
| Series | TELEPERM XP |
| Function | Pulse counting, frequency measurement, and position detection 4 pulse inputs, 24 VDC Monitoring for wire break, short circuit, and fail-safe operation |
| Input/Output | 4 pulse inputs (24 VDC, suitable for incremental encoders or proximity switches) |
| Input Voltage | 24 VDC nominal (11–30 VDC range) |
| Input Frequency | Up to 100 kHz (typical for pulse counting) |
| Power Supply | 24 VDC (via TELEPERM XP rack backplane) |
| Power Consumption | Approx. 10 W (estimated based on similar modules) |
| Environmental Specifications | Ambient Temperature: 0°C to +60°C Shock: 10 g ½ sine wave for 11 ms Vibration: 1 mm peak to peak from 2 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz Relative Humidity: 5% to 95% non-condensing |
| Dimensions | Approx. 233 mm (H) x 160 mm (W) x 20 mm (D) (standard TELEPERM XP module size) |
| Weight | Approx. 0.5 kg |
| Mounting | Plugs into TELEPERM XP rack |
| Certifications | CE, UL |
Additional Details
- The 6DP1360-8BA includes the following additional information based on industry sources:
- Function: Processes up to 4 pulse inputs for fail-safe pulse counting, frequency measurement, and position detection; supports applications like motor speed monitoring, flow measurement, and incremental encoder interfacing; monitors for wire breaks, short circuits, and ensures fail-safe operation; designed for redundant configurations to maintain reliability in critical processes.
