Siemens 6DP1230-8CC TELEPERM XP FUM 230 Analog Module
Product Overview
- The Siemens 6DP1230-8CC is a TELEPERM XP FUM 230 Analog Transmitter Signal Conditioning Module designed for the TELEPERM XP automation system. This module processes analog signals from transmitters, supporting 0/4 to 20 mA inputs in 2- or 4-wire circuits. It is used in industrial automation applications, such as chemical processing, power generation, and manufacturing, for precise monitoring and control of process variables like pressure, flow, and temperature. The module is suitable for redundant configurations to enhance system reliability.
Technical Specifications
- The 6DP1230-8CC has the following specifications based on industry sources:
| Specification | Details |
|---|---|
| Model/Part Number | 6DP1230-8CC |
| Manufacturer | Siemens |
| Description | TELEPERM XP FUM 230 Analog Transmitter Signal Conditioning Module |
| Series | TELEPERM XP |
| Function | Signal Conditioning: 16 inputs, 0/4 to 20 mA, in 2- or 4-wire circuit Transducer Supply: 24 VDC Features: 4 limit values per channel, signal correction, monitoring of transmitter supply, measurement range overshoot/undershoot, and wire break |
| Input/Output | 16 analog inputs (0/4 to 20 mA, 2- or 4-wire) Transducer supply with 24 VDC |
| Power Supply | 24 VDC (via TELEPERM XP rack backplane) |
| Power Consumption | Approx. 10 W (estimated based on similar modules) |
| Environmental Specifications | Ambient Temperature: 0°C to +60°C Shock: 10 g ½ sine wave for 11 ms Vibration: 1 mm peak to peak from 2 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz Relative Humidity: 5% to 95% non-condensing |
| Dimensions | Approx. 30 cm (H) x 4 cm (W) x 30 cm (D) |
| Weight | Approx. 0.2 kg |
| Mounting | Plugs into TELEPERM XP rack |
| Certifications | CE, UL |
Additional Details
- The 6DP1230-8CC includes the following additional information based on industry sources:
- Function: Conditions 16 analog transmitter signals (0/4 to 20 mA) in 2- or 4-wire circuits; provides 24 VDC transducer supply; supports 4 limit values per channel for threshold monitoring; enables signal correction and monitors for transmitter supply issues, measurement range overshoot/undershoot, and wire breaks; suitable for redundant setups to ensure high availability in critical applications.
