Siemens 6DP1210-8BC TELEPERM XP FUM 210 Sensor Module
Product Overview
- The Siemens 6DP1210-8BC is a TELEPERM XP FUM 210 Sensor Module designed for the TELEPERM XP automation system. This module is used for signal conditioning of sensors, specifically handling binary and analog inputs from field devices such as limit switches, proximity sensors, and temperature sensors. It is employed in industrial automation applications, including chemical processing, power generation, and manufacturing, to ensure accurate and reliable process monitoring.
Technical Specifications
- The 6DP1210-8BC has the following specifications based on industry sources:
| Specification | Details |
|---|---|
| Model/Part Number | 6DP1210-8BC |
| Manufacturer | Siemens |
| Description | TELEPERM XP FUM 210 Module for Sensor Signal Conditioning |
| Series | TELEPERM XP |
| Function | Signal Conditioning: 14 binary inputs (changeover or individual contacts) with 24 VDC supply and supervision, or analog inputs for sensors (e.g., temperature, pressure) |
| Input/Output | 14 binary inputs (24 VDC, with monitoring for wire break, short circuit to M, short circuit to P, intercore short circuit) Optional analog inputs (specific ranges not detailed in sources) |
| Power Supply | 24 VDC (via TELEPERM XP rack backplane) |
| Power Consumption | Approx. 10 W (estimated based on similar modules) |
| Environmental Specifications | Ambient Temperature: 0°C to +60°C Shock: 10 g ½ sine wave for 11 ms Vibration: 1 mm peak to peak from 2 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz Relative Humidity: 5% to 95% non-condensing |
| Dimensions | Approx. 233 mm (H) x 160 mm (W) x 20 mm (D) (standard TELEPERM XP module size) |
| Weight | Approx. 0.5 kg |
| Mounting | Plugs into TELEPERM XP rack |
| Certifications | CE, UL |
Additional Details
- The 6DP1210-8BC includes the following additional information based on industry sources:
- Function: Conditions signals from binary sensors (e.g., limit switches, proximity sensors) with 14 changeover or individual contacts and 24 VDC supply; supports analog sensor inputs for process variables like temperature or pressure; provides fault monitoring for wire breaks and short circuits; suitable for non-redundant configurations in process control.
