Siemens 6DL1193-6TP00-0DH1 Terminal Block SIMATIC ET 200SP HA
Siemens 6DL1193-6TP00-0DH1 Terminal Block SIMATIC ET 200SP HA
Manufacturer: Siemens
Product No.: 6DL1193-6TP00-0DH1
Condition:1000 in stock
Product Type: Terminal block
Product Origin: 4025515193937
Payment: T/T, Western Union
Weight: 150g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Siemens 6DL1193-6TP00-0DH1 Terminal Block for SIMATIC ET 200SP HA Systems
The Siemens 6DL1193-6TP00-0DH1 is a high-performance terminal block engineered specifically for SIMATIC ET 200SP HA (High Availability) distributed I/O systems. This terminal module delivers robust signal distribution with 32 push-in connection points, enabling rapid field wiring in demanding industrial automation environments.
Technical Specifications
- Model Number: 6DL1193-6TP00-0DH1
- System Compatibility: SIMATIC ET 200SP HA
- Connection Technology: Push-in spring terminals (32 points)
- Load Group: New generation load group architecture
- Wire Cross-Section: 0.25-2.5 mm² (AWG 24-14)
- Operating Temperature: -40°C to +70°C
- Protection Rating: IP20
- Dimensions: Compact DIN rail mounting profile
- Weight: 0.15 kg
Key Features & Benefits
Tool-Free Push-In Technology: Accelerate installation time by up to 50% with screwless push-in spring cage terminals that accept solid and ferrule-terminated conductors without additional tools.
High Availability Architecture: Designed for redundant ET 200SP HA configurations, ensuring continuous operation in mission-critical applications where downtime is not an option.
Enhanced Load Distribution: The new load group design optimizes current distribution across terminal points, reducing thermal stress and extending service life in high-density installations.
Universal Compatibility: Seamlessly integrates with SIMATIC ET 200SP HA I/O modules, BaseUnits, and server modules for flexible system expansion.
Application Scenarios
This terminal block excels in process automation, manufacturing execution systems, and infrastructure control applications requiring fault-tolerant I/O distribution:
- Chemical & Petrochemical: Redundant safety systems, emergency shutdown circuits, and continuous process monitoring
- Power Generation: Turbine control interfaces, generator protection relays, and auxiliary system wiring
- Water Treatment: Pump control stations, valve actuator connections, and SCADA field terminations
- Automotive Manufacturing: Robotic cell interfaces, conveyor control panels, and quality inspection stations
- Building Automation: HVAC control distribution, lighting management systems, and access control integration
Installation & Configuration
Mount directly onto standard 35mm DIN rails alongside ET 200SP HA BaseUnits. The color-coded terminal points and integrated labeling strips simplify wire identification during commissioning and maintenance. Compatible with TIA Portal engineering software for centralized configuration and diagnostics.
System Integration Solutions
Combine with Siemens SIMATIC controllers (S7-1500, S7-1200), distributed I/O modules, and industrial Ethernet infrastructure to build scalable automation architectures. The terminal block supports both centralized and decentralized control topologies with PROFINET communication.
Frequently Asked Questions
Q: What wire sizes are compatible with the push-in terminals?
A: The terminals accept solid and ferrule-terminated wires from 0.25 mm² to 2.5 mm² (AWG 24-14). For stranded wire, use wire-end ferrules for optimal contact reliability.
Q: Can this terminal block be used in non-HA ET 200SP systems?
A: While designed for ET 200SP HA, it's mechanically compatible with standard ET 200SP systems. However, verify electrical specifications match your application requirements.
Q: How do I release wires from push-in terminals?
A: Insert a small flat-blade screwdriver (0.4-0.6mm) into the release slot above each terminal point while gently pulling the wire.
Q: What's the maximum ambient temperature for continuous operation?
A: The terminal block is rated for -40°C to +70°C ambient temperature, suitable for most industrial cabinet environments without forced cooling.
Q: Is this product RoHS compliant?
A: Yes, the 6DL1193-6TP00-0DH1 meets RoHS directives and carries CE marking for European market compliance.
Warranty & Support
Every Siemens 6DL1193-6TP00-0DH1 Terminal Block includes a comprehensive 12-month warranty covering manufacturing defects and material failures. Our technical support team provides application assistance, replacement coordination, and integration guidance throughout the product lifecycle.
Related Products
Enhance your SIMATIC ET 200SP HA system with these complementary components:
- Siemens 6ES7193-7AA00-0AA0 SIMATIC Terminal Module - Additional terminal modules for expanded I/O capacity
- Siemens 6ES7193-1CL00-0XA0 SIMATIC DP Terminal Block TB32L - 32-point terminal block for PROFIBUS DP applications
- Siemens 6ES7193-4CD20-0AA0 SIMATIC DP Terminal Module - Compact terminal module for space-constrained installations
