Siemens 6DL1136-6DA00-0PH1 Digital Output Module - Safety-Certified I/O Solution

The Siemens 6DL1136-6DA00-0PH1 is a high-availability digital output module engineered for safety-critical industrial automation applications. Part of the ET 200SP HA distributed I/O family, this F-DQ module delivers fail-safe output control with SIL3 and Performance Level e certification, ensuring maximum operational safety in hazardous environments.

Core Technical Specifications

• Part Number: 6DL1136-6DA00-0PH1
• Product Family: SIMATIC ET 200SP HA (High Availability)
• Module Type: F-DQ (Fail-Safe Digital Output)
• Output Channels: 10 safety-rated digital outputs
• Output Voltage: 24V DC nominal
• Output Current: 2A per channel maximum
• Safety Rating: SIL3 (IEC 61508), PL e (ISO 13849-1)
• Communication: PROFINET IO with PROFIsafe protocol
• Diagnostic Coverage: >99% (DC)
• Response Time: <12ms typical for safety functions
• Operating Temperature: -40°C to +70°C extended range
• Protection Rating: IP20 standard enclosure
• Dimensions: 35mm width, compact DIN rail mounting

Industrial Application Scenarios

This safety-certified output module is purpose-built for demanding applications where human safety and process integrity are paramount:

Emergency Shutdown Systems: Controls safety actuators, emergency stop circuits, and isolation valves in chemical processing plants, refineries, and power generation facilities where immediate hazard response is critical.

Machine Safety Integration: Drives safety contactors, brake systems, and guard interlocks on automated production lines, robotic cells, and CNC machining centers to prevent operator injury during abnormal conditions.

Fire & Gas Detection: Activates suppression systems, ventilation dampers, and alarm indicators in offshore platforms, pharmaceutical cleanrooms, and food processing environments requiring rapid emergency response.

Material Handling Safety: Manages conveyor emergency stops, safety light curtain outputs, and zone isolation in warehousing, logistics centers, and airport baggage handling systems.

Process Safety Instrumented Systems (SIS): Implements final control elements in Safety Instrumented Functions (SIF) for burner management, pressure relief, and toxic gas containment applications.

Integrated Safety Solutions

The 6DL1136-6DA00-0PH1 seamlessly integrates with SIMATIC safety controllers (F-CPU) and TIA Portal engineering software, providing:

• Redundant Architecture Support: Compatible with ET 200SP HA redundant configurations for zero-downtime safety systems
• PROFIsafe Communication: Black channel transmission ensures data integrity without dedicated safety wiring
• Hot-Swap Capability: Module replacement during operation without system shutdown in HA configurations
• Comprehensive Diagnostics: Channel-level fault detection with timestamped event logging for predictive maintenance
• Flexible Wiring: Push-in terminal technology reduces installation time by 40% compared to screw terminals
• Certification Compliance: Pre-certified for global safety standards including TÜV, UL, and CSA approvals

Frequently Asked Questions

Q: What's the difference between standard DQ and F-DQ modules?
A: F-DQ modules include dual-channel safety architecture with cross-monitoring, discrepancy detection, and certified safety integrity levels. Standard DQ modules lack these safety features and cannot be used in SIL-rated applications.

Q: Can this module control standard non-safety loads?
A: Yes, while designed for safety functions, the 6DL1136-6DA00-0PH1 can control standard 24V DC loads. However, using safety-rated modules for non-safety applications may not be cost-effective.

Q: Is special programming required for safety outputs?
A: Safety logic must be programmed in a certified F-CPU using TIA Portal's safety programming environment (F-FBD/F-LAD). Standard logic blocks cannot directly control F-DQ outputs.

Q: What cable types are compatible with PROFIsafe communication?
A: Standard PROFINET cables (Cat5e or higher) are sufficient. PROFIsafe uses cryptographic data protection, so dedicated safety cabling is not required, reducing installation costs.

Warranty & Technical Support

Each Siemens 6DL1136-6DA00-0PH1 module is backed by a comprehensive 12-month manufacturer warranty covering material defects and workmanship. Our certified automation engineers provide configuration assistance, safety validation support, and rapid troubleshooting to ensure your safety systems meet regulatory compliance and operational requirements.
