Siemens 6AG1322-1BL00-2AA0 SIPLUS SM 322 Digital Output Module
Siemens 6AG1322-1BL00-2AA0 SIPLUS SM 322 Digital Output Module
Manufacturer: Siemens
Product No.: 6AG1322-1BL00-2AA0
Condition:1000 in stock
Product Type: Digital Output Module
Product Origin: 4047618045685
Payment: T/T, Western Union
Weight: 306g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Siemens 6AG1322-1BL00-2AA0 SIPLUS SM 322 Digital Output Module with Conformal Coating
The Siemens 6AG1322-1BL00-2AA0 SIPLUS SM 322 represents industrial-grade reliability engineered for demanding automation environments. This 32-channel digital output module features advanced conformal coating protection, enabling stable operation in extreme temperatures (-25°C to +60°C), high humidity, and chemically aggressive atmospheres where standard modules fail.
Technical Specifications
- Model Number: 6AG1322-1BL00-2AA0
- Output Channels: 32 digital outputs (DO 32x DC 24V/0.5A)
- Voltage Rating: 24V DC nominal
- Current per Channel: 0.5A maximum
- Conformal Coating: Class 3C3/3S3 protection against condensation, chemical agents, and biologically active substances
- Operating Temperature: -25°C to +60°C (extended range)
- Compatibility: SIMATIC S7-300 PLC systems
- Mounting: Standard S7-300 DIN rail installation
- Dimensions: 40 x 125 x 120 mm (W x H x D)
- Weight: 306g
Application Scenarios
This SIPLUS module excels in harsh industrial sectors including chemical processing plants, offshore oil platforms, wastewater treatment facilities, food and beverage production lines, and automotive paint shops. The conformal coating shields sensitive electronics from corrosive fumes, salt spray, and condensation, ensuring uninterrupted control of solenoid valves, motor contactors, indicator lights, and pneumatic actuators in challenging conditions.
Engineering Solutions
Integrate seamlessly into existing S7-300 architectures without programming modifications. The module supports hot-swapping for minimal downtime during maintenance, features diagnostic LEDs for rapid troubleshooting, and provides short-circuit protection on every channel. Pair with SIMATIC STEP 7 software for intuitive configuration and real-time monitoring of output states.
Frequently Asked Questions
Q: What distinguishes SIPLUS from standard SM 322 modules?
A: SIPLUS variants include conformal coating and extended temperature ratings (-25°C to +60°C vs. 0°C to +60°C), making them suitable for extreme environmental conditions.
Q: Can this module control AC loads?
A: No, this is a DC output module rated for 24V DC loads only. For AC switching, consider relay output modules like the 6ES7322-5HF00-0AB0.
Q: Is the conformal coating repairable if damaged?
A: Conformal coating is factory-applied and not field-serviceable. Damaged modules should be replaced to maintain environmental protection.
Q: What front connector is required?
A: Use Siemens 6ES7392-1BM01-0AA0 40-pin front connector for proper termination.
Warranty & Support
Every unit includes a 12-month manufacturer warranty covering defects in materials and workmanship. Our technical support team provides application assistance, wiring diagrams, and integration guidance throughout your project lifecycle.
Related Products
| Product | Description | Link |
|---|---|---|
| Siemens 6ES7322-1BL00-0AB0 | SM 322 Digital Output Module 32DO 24VDC (Standard Version) | View Product |
| Siemens 6ES7322-1BH01-0AA0 | SM 322 Digital Output Module 16DO 24VDC/2A | View Product |
| Siemens 6ES7322-5HF00-0AB0 | SM 322 Relay Output Module 8DO 120/230VAC | View Product |
