Product Description
General Information
|
Field |
Detail |
|---|---|
|
Manufacturer |
Siemens |
|
Model/Part Number |
5SU1354-7KK16 |
|
Description |
RCBO (Residual Current Circuit Breaker with Overcurrent Protection), 10 kA, 1P+N, Type A, 30 mA sensitivity, C-characteristic, 16 A rated current, 230 V AC rated voltage |
|
Product Family |
RCBOs |
|
Product Lifecycle (PLM) |
PM300: Active Product |
Technical Specifications
|
Specification |
Detail |
|---|---|
|
Breaking Capacity |
10 kA |
|
Poles |
1P+N |
|
Type |
A |
|
Residual Current Sensitivity |
30 mA |
|
Tripping Characteristic |
C |
|
Rated Current (In) |
16 A |
|
Rated Voltage (Un AC) |
230 V |
Physical & Packaging Details
|
Specification |
Detail |
|---|---|
|
Net Weight |
0.270 kg |
|
Packaging Dimensions (L x W x H) |
40.00 x 96.00 x 82.00 mm |
Additional Product Information
|
Specification |
Detail |
|---|---|
|
Article Number |
5SU1354-7KK16 |
|
EAN |
4001869307848 |
|
UPC |
Not available |
|
Commodity Code |
85362010 |
|
Catalog ID (LKZ_FDB) |
LV10.1 |
|
Product Group |
5516 |
|
Group Code |
P310 |
|
Country of Origin |
Romania |
|
RoHS Compliance |
Since: 01.06.2006 |
|
Product Class |
A: Stock item, returnable within guidelines |
|
WEEE Take-Back Obligation |
Yes |
|
REACH Art. 33 Notification |
- Lead (CAS-No. 7439-92-1) > 0.1% w/w - Lead monoxide (CAS-No. 1317-36-8) > 0.1% w/w |
|
SCIP Number |
31c66a08-dffe-42ae-949f-d1ad6081277a |
