Schneider ABL8REM24050 Modicon Power Supply
Schneider ABL8REM24050 Modicon Power Supply
Manufacturer: Schneider
Product No.: ABL8REM24050
Condition:1000 in stock
Product Type: Modicon Power Supply
Product Origin: USA
Payment: T/T, Western Union
Weight: 803g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
General Information
|
Field |
Details |
|---|---|
|
Manufacturer |
Schneider Electric |
|
Model/Part Number |
ABL8REM24050 |
|
Description |
Regulated switch mode power supply, Modicon, 1 or 2 phase, 100_240V AC, 24V DC, 5A |
_
_
Technical Specifications
|
Category |
Specification |
|---|---|
|
Range of Product |
Modicon Power Supply |
|
Product Type |
Power Supply |
|
Power Supply Type |
Regulated switch mode |
|
Nominal Input Voltage |
- 100_240 V AC (phase-to-phase or single-phase)__- 110_220 V DC |
|
Input Voltage Limits |
- 85_264 V AC__- 100_250 V DC |
|
Input Protection |
Integrated fuse (non-replaceable) |
|
Rated Power |
120 W |
|
Output Voltage |
24 V DC (adjustable 100_120%) |
|
Output Current |
5 A |
|
Output Coupling |
Series or Parallel |
|
Efficiency |
85% |
|
Power Factor |
0.65 at 24 V DC |
|
Inrush Current |
30 A |
|
Power Dissipation |
21.2 W |
|
Current Consumption |
1.2 A @ 240 V AC__1.9 A @ 100 V AC |
|
Output Protection |
- Overload (1.1 _ In)__- Overvoltage (>1.5 _ Un, tripping)__- Short-circuit (automatic reset)__- Undervoltage (<0.8 _ Un, tripping) |
|
Status LEDs |
- 1 green (output voltage)__- 1 orange (input voltage) |
_
_
Connection Terminals
|
Function |
Type and Size |
|---|---|
|
Input Connection |
Screw terminals: 2 _ 0.14_2.5 mm² (AWG 26_14) |
|
Output Connection |
Screw terminals: 4 _ 0.14_2.5 mm² (AWG 26_14) |
|
Input Ground |
Screw terminal: 1 _ 0.14_2.5 mm² (AWG 26_14) |
|
Output Ground |
Screw terminals: 2 _ 0.14_2.5 mm² (AWG 26_14) |
_
_
Physical Specifications
|
Parameter |
Value |
|---|---|
|
Width |
54 mm |
|
Height |
120 mm |
|
Depth |
120 mm |
|
Net Weight |
1 kg |
|
Mounting |
DIN rail: 35_15 mm, 75_7.5 mm, 35_7.5 mm |
|
Operating Position |
Vertical |
_
_
Electrical Safety
|
Compliance/Standard |
Details |
|---|---|
|
SELV |
Conforming to IEC 60950-1, IEC 60204-1, IEC 60364-4-41 |
|
Dielectric Strength |
- 3000 V input to ground__- 3000 V input to output__- 500 V output to ground__- 500 V output to output |
_
_
Environmental Limits
|
Parameter |
Value |
|---|---|
|
Operating Altitude |
2000 m |
|
Ambient Operating Temperature |
0_50__ without derating__50_60__ with derating |
|
IP Rating |
IP20 (IEC 60529) |
_
_
Certifications & Compliance
|
Standards |
Certifications |
|---|---|
|
UL 508, CSA C22.2 No 60950-1, EN/IEC 62368-1 |
UL, RCM, EAC, KC, CCSAus |
|
EMC: EN 50081-1, EN 50082-2, EN 55024 |
Safety: EN/IEC 60950 |
_
_
Packing Information
|
Unit |
Value |
|---|---|
|
Package Type |
PCE |
|
Units per Package |
1 |
|
Package Dimensions (L_W_H) |
14.5 _ 13.3 _ 6.7 cm |
|
Package Weight |
803 g |
_
