Product Overview: Schneider Electric 1000BASELX Uplink Module
The 1000BASELX is a fiber-optic uplink module manufactured by Schneider Electric, typically used in conjunction with managed network switches such as the S4 Chassis Managed Switch (P0973KD). It facilitates high-speed uplink connections over long distances using single-mode or multimode fiber in industrial automation and networking environments.
📦
General Information
|
Attribute |
Details |
|---|---|
|
Manufacturer |
Schneider Electric |
|
Model/Part Number |
1000BASELX |
|
Description |
Uplink Module |
|
Compatible Chassis |
S4 Chassis Managed Switch (P0973KD) |
🔌
Interface & Media Support
|
Attribute |
Details |
|---|---|
|
Fiber Type |
MMF (62.5 µm), SMF (9 µm), S-SMF (9 µm) |
|
Connector Type |
LC connector |
|
Supported Standards |
1000Base-SX, 1000Base-LX, 1000Base-LX/LH, 1000Base-BX, 1000Base-ZX |
|
Copper Interface |
1000Base-T, RJ-45 (when applicable) |
|
Cable Types |
STP CAT5 (for copper), various fiber types |
📏
S4 Chassis Physical Specifications (P0973KD)
|
Attribute |
Specification |
|---|---|
|
Mounting |
Desk or 19-inch equipment rack (9U) |
|
Height |
40 cm (15.75 in) |
|
Width |
44.7 cm (17.6 in) |
|
Depth |
47.32 cm (18.63 in) |
|
Weight (Approx.) |
24.7 kg (54.45 lb) |
✅
Regulatory Compliance and Certifications
|
Category |
Standards Met |
|---|---|
|
EMC |
47 CFR Parts 2 & 15, CSA C108.8, 89/336/EEC, EN 55022, EN 61000-3-2/-3, etc. |
|
Product Safety |
UL 60950, CSA C22.2 No. 60950, EN 60950, IEC 60950 |
|
Laser Safety (If Applicable) |
EN 60825, 21 CFR 1040.10 |
|
Installation Location |
UL/UL-C listed for ordinary locations; compliant with safety standards |
|
Contamination Level |
Class G1 (Mild) – per ISA Standard S71.04 |
