Product Description
General Information
|
Manufacturer |
Prosoft |
|---|---|
|
Model/Part Number |
MVI56E-MNETC |
|
Description |
Modbus TCP/IP Client Enhanced Communication Module |
Hardware Specifications
|
Specification |
Description |
|---|---|
|
Dimensions |
Standard 1756 ControlLogix® single-slot module |
|
Backplane Current Load |
800 mA @ 5 VDC 3 mA @ 24 VDC |
|
Operating Temperature |
0°C to 60°C (32°F to 140°F) -25°C to 70°C (-13°F to 140°F) - MVI56E-MNETCXT |
|
Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
|
Extreme/Harsh Environment |
MVI56E-MNETXT comes with conformal coating |
|
Shock |
30 g operational 50 g non-operational |
|
Vibration |
5 g from 10 to 150 Hz |
|
Relative Humidity |
5% to 95% (with no condensation) |
|
LED Indicators |
- Application Status (APP) - Module Status (OK) - 4-character scrolling alphanumeric LED display (Shows module, version, IP, application port setting, port status, and error information) |
|
Ethernet Port |
10/100 Base-T, RJ45 Connector, for CAT5 cable Link and Activity LED indicators Auto-crossover cable detection |
