Product Description
Product Details
| Parameter | Details |
|---|---|
| Manufacturer | ABB |
| Model/Part Number | NIMP01 |
| Description | Multi-Function Processor Termination Module |
Product Overview
| Parameter | Details |
|---|---|
| Part Number | NIMP01 |
| Product Name | NIMP01 Multi-Function Processor Termination Module |
| Application | Termination and interfacing for communication cables in distributed control systems |
| Compatibility | Integrates with ABB Bailey INFI 90 and Network 90 systems |
| Function | Provides versatile termination for system components, supports communication protocols and signal interfacing |
Functional Specifications
| Parameter | Details |
|---|---|
| Type | Processor termination module with multi-function capabilities |
| Power Supply | +5 V DC |
| Power Consumption | 3 VA |
| Communication Protocols | Network 90/INFI 90 proprietary, RS-232, RS-422 |
| Dimensions | 6U high, 1U wide, 2U deep |
| Operating Temperature Range | -30°C to +70°C |
| Mounting | Rack mount in control cabinet |
| Weight | 0.5 kg approximate |
| Standards Compliance | IEC 61131-2, CE, UL, CSA |
