NIMF01 | ABB Network Interface Module for CNET Communication
NIMF01 | ABB Network Interface Module for CNET Communication
Manufacturer: ABB
Product No.: NIMF01
Condition:1000 in stock
Product Type: Network Interface Module
Product Origin: 8719264037456
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
ABB NIMF01 Network Interface Module - High-Speed CNET Communication Solution
The ABB NIMF01 Network Interface Module delivers robust fiber optic connectivity for mission-critical industrial automation networks. Engineered for seamless integration with ABB Symphony Plus, Bailey INFI 90, and Harmony distributed control systems, this module ensures reliable data exchange across CNET global data networks in process industries.
Technical Specifications
- Part Number: NIMF01
- Interface Type: Dual fiber optic ports with redundant communication
- Protocol Support: CNET high-speed data transmission protocol
- Data Transfer Rate: Up to 10 Mbps
- Electrical Isolation: 500V galvanic isolation between ports and system
- Power Requirements: 24V DC nominal (18-30V DC range), 5W max consumption
- Operating Temperature: -30°C to +70°C (-22°F to +158°F)
- Mounting Options: DIN rail or rack mount installation
- Dimensions: 160mm × 100mm × 50mm (W × H × D)
- Weight: 0.5 kg (1.1 lbs)
- Compliance: IEC 61131-2, CE, UL, CSA certified
Key Applications & Solutions
Process Automation Integration: The NIMF01 serves as the critical communication backbone in oil & gas refineries, chemical plants, power generation facilities, and pharmaceutical manufacturing environments where real-time data integrity is non-negotiable.
System Redundancy: Dual fiber optic ports enable fault-tolerant network architectures, ensuring continuous operation even during single-point failures. This redundancy design minimizes unplanned downtime and supports 24/7 production schedules.
Multi-System Connectivity: Bridge legacy Bailey INFI 90 systems with modern Symphony Plus controllers through standardized CNET protocol, enabling phased migration strategies without complete system overhauls.
Performance Advantages
The fiber optic interface eliminates electromagnetic interference concerns in electrically noisy industrial environments. With 500V galvanic isolation, the module protects sensitive control equipment from ground loops and voltage transients common in large-scale facilities.
Wide operating temperature tolerance (-30°C to +70°C) ensures reliable performance in extreme climates and non-climate-controlled enclosures, reducing HVAC requirements and installation costs.
Installation & Integration
Compact DIN rail mounting simplifies retrofit installations in existing control cabinets. The module's 24V DC power supply aligns with standard industrial control voltage, eliminating the need for additional power conversion equipment. Plug-and-play compatibility with ABB control platforms reduces commissioning time and engineering overhead.
Related Products
| Product | Description | Link |
|---|---|---|
| NTCL01 (6636997L1) | ABB Communication Link Termination Unit for INFI 90 networks | View Product |
| INNPM12 | ABB Network Processor Module for distributed control systems | View Product |
| PNI800 | ABB Plant Network Interface Module for Symphony Plus integration | View Product |
Quality Assurance
All NIMF01 modules undergo rigorous factory testing and comply with international industrial automation standards. Each unit is verified for protocol compatibility, isolation integrity, and environmental performance before shipment.
