Product Description
product Details
| Parameter | Details |
|---|---|
| Manufacturer | ABB |
| Model/Part Number | NIMF01 |
| Description | Network Interface Module |
Product Overview
| Parameter | Details |
|---|---|
| Part Number | NIMF01 |
| Product Name | NIMF01 Network Interface Module |
| Application | Network communication interface in distributed control systems for industrial process automation |
| Compatibility | Integrates with ABB Symphony Plus, Bailey INFI 90, and Harmony systems; supports CNET global data network |
| Function | Provides network connectivity for controllers, enables data exchange and system integration |
Functional Specifications
| Parameter | Details |
|---|---|
| Type | Fiber optic network interface for CNET |
| Protocol Support | CNET protocol for high-speed data transmission |
| Ports | Dual fiber optic ports for redundant communication |
| Data Rate | Up to 10 Mbps |
| Isolation | Galvanic isolation (500 V) between ports and system |
| Power Supply | 24 V DC nominal (18-30 V DC) |
| Power Consumption | 5 W maximum |
| Operating Temperature Range | -30°C to +70°C |
| Mounting | DIN rail or rack mount in control cabinet |
| Dimensions | 160 mm x 100 mm x 50 mm (W x H x D) approximate |
| Weight | 0.5 kg |
| Standards Compliance | IEC 61131-2, CE, UL, CSA |
