Product Description
Product Details:
- Manufacturer: BACHMANN
- Model/Part Number: MPC293
- Description: CPU Processor Modules
| Feature | Details |
|---|---|
| CPU | Celeron / Pentium III architecture (embedded), 400 / 650 / 700 MHz 933 MHz |
| Mass Storage (CF) | Without restriction |
| Data Memory (nvRAM-0) | 512 kB SRAM, battery-backed |
| Data Memory (nvRAM-1) | 64 kB nvRAM (no battery necessary) |
| Working Memory (DRAM) | 128 MB |
| Program Memory (PC Card) | PCC201 / xx with 32 / 64 MB FLASH |
| Internal FLASH (Program Memory) | 8 MB, 4 MB reserved for system software |
| Interfaces | - Serial: 1x RS232 + 1x RS232/422/485 |
| - Ethernet: 2x 10/100 Base-TX | |
| - USB: 1x | |
| Power Supply | External power supply module 5 V, ±15 V via backplane |
| Additional Features | - Watchdog |
| - Synchronizing pulse for SERCOS, CAN, and Ethernet fieldbus | |
| - Real-time clock with battery | |
| - Status indication via 3 LEDs | |
| - CPU-ID selectable with rotary hexadecimal switches | |
| Execution Variants | CPU module P III (933MHz); 512kB SRAM; 64kB nvRAM; 8MB fileflash; 2x Eth100; 1x RS232; 1x RS232/422/485; 1x USB1.1; PCC slot; CF slot |
| Like MPC293; ColdClimate (❉) |
