KJ3002X1-BA1 Emerson DeltaV 8-Channel 24VDC Digital Output Module
KJ3002X1-BA1 Emerson DeltaV 8-Channel 24VDC Digital Output Module
Manufacturer: EMERSON
Product No.: KJ3002X1-BA1| 12P0680X122 | 12P0680X072
Condition:1000 in stock
Product Type: Digital Output Module
Product Origin: 8865810022659
Payment: T/T, Western Union
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
- 24/7 Support
- 30-Day Returns
- Fast Shipping
Emerson KJ3002X1-BA1 DeltaV 8-Channel Digital Output Module
The Emerson KJ3002X1-BA1 is a high-performance 8-channel digital output module engineered for DeltaV distributed control systems. This high-side switching module delivers reliable 24VDC output control for industrial automation applications requiring precise actuator and valve management.
Technical Specifications
- Model Number: KJ3002X1-BA1 (Alt: 12P0680X122, 12P0680X072)
- Output Channels: 8 independent digital outputs
- Output Type: 24VDC high-side switching
- Local Bus Power: 12 VDC at 150 mA
- Field Voltage Rating: Up to 30 VDC
- Current Capacity: 2A per channel (typical)
- Isolation: Channel-to-channel and channel-to-bus isolation
- Diagnostics: Built-in short-circuit and overload protection
- Compatibility: DeltaV S-series and M-series controllers
Key Features & Benefits
Robust High-Side Switching: Provides positive voltage switching for solenoid valves, motor starters, and relay coils with superior noise immunity compared to low-side configurations.
Advanced Diagnostics: Real-time channel status monitoring detects open circuits, short circuits, and overload conditions, enabling predictive maintenance and reducing unplanned downtime.
Hot-Swappable Design: Field-replaceable without system shutdown, minimizing process interruptions during maintenance or upgrades.
Flexible Integration: Seamlessly integrates with DeltaV CHARMs, terminal blocks, and I/O subsystems for scalable automation architectures.
Application Solutions
Valve Control Systems: Precisely control pneumatic and hydraulic solenoid valves in chemical processing, oil & gas, and water treatment facilities. The module's high-side switching ensures fail-safe operation during power anomalies.
Motor & Actuator Management: Drive electric actuators, damper motors, and variable frequency drive enable signals in HVAC, power generation, and manufacturing environments.
Safety Instrumented Systems (SIS): Deploy in safety-critical applications requiring SIL-rated output control for emergency shutdown valves and fire suppression systems when paired with certified DeltaV SIS controllers.
Batch Process Control: Manage sequential operations in pharmaceutical, food & beverage, and specialty chemical production with precise timing and interlock logic.
Installation & Configuration
The KJ3002X1-BA1 mounts directly to DeltaV carrier cards and connects via industry-standard terminal blocks. Configuration is performed through DeltaV Explorer software with automatic channel assignment and parameter tuning. Field wiring supports both shielded and unshielded cables with recommended wire gauges of 14-22 AWG.
Quality & Reliability
Manufactured to Emerson's stringent quality standards, this module features conformal coating for harsh industrial environments, extended temperature range operation (-40°C to +70°C), and MTBF exceeding 500,000 hours. Backed by Emerson's global support network and comprehensive warranty coverage.
