Product Description
General Information
|
Manufacturer |
ICS Triplex |
|---|---|
|
Model/Part Number |
T8110B |
|
Description |
Trusted TMR Processor |
Electrical Specifications
|
Parameter |
Specification |
|---|---|
|
Voltage Range |
20 to 32V DC |
|
Maximum Load |
75W |
|
Heat Dissipation |
70W |
|
Use With Chassis |
T8100 |
|
Processor Clock |
100MHz |
Memory Specifications
|
Memory Type |
Size |
|---|---|
|
DRAM |
16MB EDO 60ns |
|
EPROM |
512kB |
|
FLASH |
2MB |
|
NVRAM |
128kB |
I/O Interface
|
Interface |
Specification |
|---|---|
|
I/O Bus |
Triple redundant Inter-Module Bus |
Mechanical Specifications
|
Dimension |
Value |
|---|---|
|
Height |
241mm (9.5 in) |
|
Width |
90mm (3.6 in) |
|
Depth |
300mm (11.8 in) |
|
Weight |
2.71kg (5.95 lbs) |
Environmental Specifications
|
Parameter |
Specification |
|---|---|
|
Operating Temperature |
-5°C to 60°C (23°F to 140°F) |
|
Operating Humidity |
5% to 95%, non-condensing |
|
Vibration |
10 to 57Hz ±0.075mm, 57 to 150Hz 1.0g |
|
Shock |
15g, ½ sine wave, 11ms |
EMI Compliance (IEC 801)
|
Parameter |
Specification |
|---|---|
|
ESD (Electrostatic Discharge) |
Air discharge to 15kV, Contact discharge to 8kV |
|
Radiated Fields |
10V/m, 27MHz to 500MHz |
|
Transients and Bursts |
2kV, 2.5kHz for t=60 seconds |
