Product Description
Product Overview
| Category | Details |
|---|---|
| Manufacturer | Honeywell |
| Model/Part Number | TC-OAV081 |
| Description | Analog Output Module designed for Honeywell Experion PKS and TDC systems, providing 8 channels for precise voltage or current output control in industrial automation |
| Key Features | 8 analog output channels, supports 4-20 mA and ±10.4 V outputs, high resolution, overvoltage protection, compatible with C200/C200E controllers, DIN rail-mountable |
Technical Specifications
| Specification | Details |
|---|---|
| Model | TC-OAV081 |
| Product Type | Analog Output Module |
| Series | Experion PKS, TDC 2000/3000/5000 |
| Number of Channels | 8 |
| Output Type | Current (0-21 mA), Voltage (±10.4 V) |
| Current Resolution | 650 µA per count |
| Voltage Resolution | 320 µV per count |
| Drive Capability | 0-750 Ω (Current), >2000 Ω (Voltage) |
| Output Protection | 24 VAC/VDC overvoltage, short circuit limited to 21 mA |
| Power Supply | 24 VDC (via system backplane) |
| Operating Temperature | -25°C to 70°C (-13°F to 158°F) |
| Dimensions | 100 x 70 x 30 mm (3.94 x 2.76 x 1.18 in) |
| Weight | Approx. 0.24 kg (0.53 lbs) |
External Connection Options
| Connection Type | Details |
|---|---|
| Supported Connections | Terminal blocks for field wiring, integrates with Experion PKS and TDC system backplanes |
Functional Features
| Feature | Details |
|---|---|
| Analog Control | Precise control of actuators, valves, and other field devices |
| Protection | Overvoltage and short circuit protection for reliable operation |
| Compatibility | Works with Honeywell C200/C200E controllers and legacy TDC systems |
| Installation | DIN rail-mountable for easy setup in control cabinets |
Model and Configuration
| Category | Details |
|---|---|
| Base Model | TC-OAV081 |
| Configuration | Standard 8-channel analog output, non-coated |
Applications and Benefits
| Category | Details |
|---|---|
| Applications | Process automation in oil and gas, chemical, power generation, and manufacturing industries |
| Benefits | High precision output control, robust protection features, easy integration, reliable performance in harsh environments |
