Product Description
Product Overview
| Category | Details |
|---|---|
| Manufacturer | Honeywell |
| Model/Part Number | SC-UMX01 |
| Description | Safety Manager SC designed for Honeywell Safety Systems, a third-generation safety platform using Quad Modular Redundant (QMR) architecture for safety-critical applications up to SIL 3 |
| Key Features | Universal I/O technology, QMR (2oo4D) architecture, SIL 3 certified, offline virtualization, cloud engineering support, modular and scalable design, supports remote I/O |
Technical Specifications
| Specification | Details |
|---|---|
| Model | SC-UMX01 |
| Product Type | Safety Manager SC System |
| Series | Safety Manager SC |
| I/O Types | Analog Input (AI), Analog Output (AO), Digital Input (DI), Digital Output (DO) |
| Safety Integrity Level | SIL 3 (IEC 61508, TÜV certified) |
| Architecture | Quad Modular Redundant (2oo4D) |
| Power Supply | 24 VDC |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Weight | Approx. 5-10 kg (11-22 lbs, system-dependent) |
External Connection Options
| Connection Type | Details |
|---|---|
| Supported Connections | Universal I/O modules, field wiring via terminal blocks, integrates with DCS/PLC systems, supports remote I/O connectivity |
Functional Features
| Feature | Details |
|---|---|
| Universal I/O | Each channel configurable for AI, AO, DI, or DO |
| Safety Applications | Emergency Shutdown (ESD), Fire & Gas, Burner Management, HIPPS, Critical Control |
| Virtualization | Offline simulation for system design and testing |
| Scalability | Modular design for small to large distributed architectures |
Model and Configuration
| Category | Details |
|---|---|
| Base Model | SC-UMX01 |
| Configuration | Standard Safety Manager SC with universal I/O |
Applications and Benefits
| Category | Details |
|---|---|
| Applications | Process safety in oil and gas, chemical, power generation, and refining industries |
| Benefits | High safety and availability, flexible I/O configuration, reduced footprint, up to 30% capital savings, compliance with global safety standards |
