| Processor |
High-performance processor for real-time control |
| Memory |
256 MB DRAM |
| I/O Channels |
28 onboard mixed I/O (configurable as 24 digital inputs/16 digital outputs or analog I/O) |
| Expansion Capability |
Up to 30 expansion I/O modules, 5 rows of expansion I/O |
| Communication Ports |
2 RS485 ports, 2 RS232 ports, 4 Ethernet ports, 1 SD Card slot |
| Supported Protocols |
Modbus TCP/IP, Modbus RTU, OPC UA, DNP3, Honeywell proprietary protocols |
| Power Supply |
24 V DC (18 to 30 V DC range) |
| Power Consumption |
1.7 W (minimum, no expansion IOMs), 2.9 W (maximum, no expansion IOMs), 3.4 W (maximum with expansion IOMs) |
| Maximum Input Current |
1.20 A at 30 V DC (controller plus 9 I/O modules) |
| Status Indicators |
LED indicators for power, communication, and module status |
| Operating Temperature Range |
-40 to 75°C |
| Mounting |
Standard 35mm DIN rail |
| Dimensions |
220 mm x 150 mm x 80 mm (W x H x D) |
| Weight |
1830 g |
| Standards Compliance |
CE, TUV, UL508, CSA, ATEX, IECEx |
