Honeywell SC-UCMX02 51307195-276 Non-redundant Controller with 28 Mixed I/O

Honeywell SC-UCMX02 51307195-276 Non-redundant Controller with 28 Mixed I/O

  • Manufacturer: Honeywell

  • Product No.: 51307195-276

  • Condition:1000 in stock

  • Product Type: Non-redundant Controller with 28 Mixed I/O

  • Product Origin: USA

  • Payment: T/T, Western Union

  • Weight: 1000g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

SC-UCMX02 51307195-276 Parameters

Product Overview

Parameter Details
Part Number SC-UCMX02 51307195-276
Product Name Non-redundant Controller with 28 Mixed I/O
Application Controller for ControlEdge RTU 2020 platform
Compatibility Interfaces with ControlEdge RTU I/O modules and Experion SCADA
Function Provides processing, control, and mixed I/O for industrial automation

Functional Specifications

Parameter Details
Processor High-performance processor for real-time control
Memory 256 MB DRAM
I/O Channels 28 onboard mixed I/O (configurable analog/digital inputs/outputs)
Expansion Capability Up to 30 expansion I/O modules, 5 rows of expansion I/O
Communication Ports 2 RS485 ports, 2 RS232 ports, 4 Ethernet ports, 1 SD Card slot
Supported Protocols Modbus TCP/IP, OPC UA, Honeywell proprietary protocols
Power Supply 24 V DC (18 to 30 V DC range)
Power Consumption 1.7 W (minimum, no expansion IOMs), 2.9 W (maximum, no expansion IOMs), 3.4 W (maximum with expansion IOMs)
Maximum Input Current 1.20 A at 30 V DC (controller plus 9 I/O modules)
Status Indicators LED indicators for power, communication, and module status
Ambient Temperature Range -40 to 70°C
Mounting Standard 35mm DIN rail
Dimensions 190 mm x 99 mm x 141 mm (L x W x H)
Weight 700 g
Standards Compliance CE, TUV, UL508, CSA, ATEX, IECEx



View full details

Product Description

SC-UCMX02 51307195-276 Parameters

Product Overview

Parameter Details
Part Number SC-UCMX02 51307195-276
Product Name Non-redundant Controller with 28 Mixed I/O
Application Controller for ControlEdge RTU 2020 platform
Compatibility Interfaces with ControlEdge RTU I/O modules and Experion SCADA
Function Provides processing, control, and mixed I/O for industrial automation

Functional Specifications

Parameter Details
Processor High-performance processor for real-time control
Memory 256 MB DRAM
I/O Channels 28 onboard mixed I/O (configurable analog/digital inputs/outputs)
Expansion Capability Up to 30 expansion I/O modules, 5 rows of expansion I/O
Communication Ports 2 RS485 ports, 2 RS232 ports, 4 Ethernet ports, 1 SD Card slot
Supported Protocols Modbus TCP/IP, OPC UA, Honeywell proprietary protocols
Power Supply 24 V DC (18 to 30 V DC range)
Power Consumption 1.7 W (minimum, no expansion IOMs), 2.9 W (maximum, no expansion IOMs), 3.4 W (maximum with expansion IOMs)
Maximum Input Current 1.20 A at 30 V DC (controller plus 9 I/O modules)
Status Indicators LED indicators for power, communication, and module status
Ambient Temperature Range -40 to 70°C
Mounting Standard 35mm DIN rail
Dimensions 190 mm x 99 mm x 141 mm (L x W x H)
Weight 700 g
Standards Compliance CE, TUV, UL508, CSA, ATEX, IECEx
