| Channels |
16 thermocouple or mV input channels |
| Input Types |
Thermocouples (J, K, T, E, N, R, S, B), mV inputs |
| Channel Isolation |
64 fully-isolated channels (channel-to-channel, channel-to-PM, channel-to-power supply) in 16-channel increments |
| Cold Junction Compensation |
Remote cold junction capability |
| Scanning Rate |
1-second process variable (PV) scanning with open thermocouple detection (OTD) |
| OTD Protection |
Configurable, performed every 30 seconds for all points |
| Power Consumption |
0.15 A @ 24 VDC |
| Ambient Temperature Range |
0 to 60°C |
| Mounting |
Standard 35mm DIN rail or panel mount |
| Dimensions |
3.2 cm x 10.7 cm x 13 cm (L x W x H) |
| Weight |
0.85 kg |
| Standards Compliance |
CE, ATEX (II 3G EEx nA [nL] IIC T4), UL (Class I, Div. 2, Groups A, B, C, D; T4), IEC 61131-2 |
