Product Description
General Information
|
Manufacturer |
Honeywell |
|---|---|
|
Model/Part Number |
FS-SAI-1620m |
|
Alternative Type Numbers |
FC-SAI-1620m, FA-SAI-1620m |
|
Description |
Input Module |
|
Approvals |
CE, TUV, UL, CSA, FM |
|
Space Requirements |
4 TE, 3 HE (= 4 HP, 3U) |
Power Requirements
|
Voltage |
Current Consumption |
|---|---|
|
5 V DC |
35 mA |
|
24 V DC |
35 mA |
Input Specifications
|
Parameter |
Specification |
|---|---|
|
Number of Input Channels |
16 |
|
Input Range |
0-4.1 V |
|
Input Resistance |
> 1 MΩ |
|
Maximum Load Capacitance |
100 nF |
|
A/D Converter |
12-bit |
|
A/D Converter Inaccuracy |
± 1 LSB |
|
Module Inaccuracy |
< 0.25% |
|
Absolute Max. Input Signal |
± 36 V DC |
|
Cross Talk Between Channels |
> 60 dB |
External Voltage Read Back
|
Range |
0-4.1 V |
|---|---|
|
Input Resistance |
Typically 1 MΩ |
Key Coding & Connectors
|
Module Connector Code |
Holes A5, C25 |
|---|---|
|
Chassis Connector Code |
Large pins A5, C25 |
